INFINITY
',$*1267,&6
6&5((1$/,*10(17
5.22 User Manual Software Version 7
SCREEN ALIGNMENT
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The menu bar changes to the following:
Next / Previous keys have no function in this application.
Incr. / Decr. keys change the value of the cycle count.
Exit returns operation to the screen alignment diagnostics page.
Home Actuators Selecting this diagnostic function drives the X forward, X Rear and Y Axis
actuators simultaneously to their home positions, as determined by their home
sensors.
Drive X Forward
Motor Using Jog
Buttons
Selecting this diagnostic function drives the X forward actuator using the jog
buttons. The right Jog button drives the X forward actuator right at slow speed
and the left Jog button drives it left, stopping immediately the button is released.
Drive X Rear
Motor Using Jog
Buttons
Selecting this diagnostic function drives the X rear actuator using the jog
buttons. The right jog button drives the X rear actuator right at slow speed and
the left jog button drives it left, stopping immediately the button is released.
Cycle Count
Done :-
0, To go :-
50
ON
Home Actuators
Drive X Forward Motor Using Jog Buttons
Drive X Rear Motor Using Jog Buttons
Drive Y Motor Using Jog Buttons
Toggle Chase Clamp
Cycle Alignment System
Screen Alignment Diagnostics
Run
Diagnost
Adjust Next Previous Exit
Actuator Cycle Test Parameters
CYCLE COUNT
50.0
Cycles
Next Previous Incr. Decr. Exit
INFINITY
',$*1267,&6
6&5((1$/,*10(17
Software Version 7 User Manual 5.23
Drive Y Motor
Using Jog Buttons
Selecting this diagnostic function drives the Y actuator using the jog buttons.
The right jog button drives the Y actuator forward at slow speed and the left jog
button drives it to the rear, stopping immediately the button is released.
Toggle Chase
Clamp
Selecting this diagnostic function alternately energizes and de-energizes the
chase clamp solenoid, displaying On when the clamps are energized and Off
when the clamps are de-energized.
Cycle Alignment
System
Selecting this diagnostic function starts a continuous cycle of driving the screen
actuators to each of the positions in the table below in sequence, dwelling for 2
seconds at each point and continuing the cycle.
The positions are given as XF, XR and Y in mm from the home position and are
as follows:
If data logging is enabled, every time the screen returns to 0,0,0, locate a screen
fiducial and its coordinates are appended to:
D:\Program Files\DEK\MachineControl\Printer\Screen.Dat file.
This continuous cycling is terminated by selecting the stop key or when the set
cycle count has been reached.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
1 0, 0, 0.
2 +20, +10, +10.
3 0, 0, 0.
4 -20, -10, -10.
5 0, 0, 0.
6 +10, +20, -10.
7 0, 0, 0.
8 -10, -20, +10.
INFINITY
',$*1267,&6
6&5((1&+$1*(
5.24 User Manual Software Version 7
SCREEN CHANGE
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Home Screen
Motor
Selecting this diagnostic function drives the screen motor to its home position,
as set by its home sensor.
Move Screen
Motor Using Jog
Buttons
Selecting this diagnostic function drives the screen motor using the jog buttons.
The right jog button drives the screen motor forward and the left jog button
drives it to the rear, stopping immediately the button is released.
Toggle Coupling
Right
Selecting this diagnostic function alternately energizes and de-energizes the
drive coupling right solenoid, displaying On when energized and Off when de-
energized.
Toggle Coupling
Left
Selecting this diagnostic function alternately energizes and de-energizes the
drive coupling left solenoid, displaying On when energized and Off when de-
energized.
Toggle Drive
Coupling
Selecting this diagnostic function alternately energizes and de-energizes the
drive couplings, displaying On when energized and Off when de-energized.
Toggle Screen
Clamps
Selecting this diagnostic function alternately energizes and de-energizes the
screen clamps, displaying ‘On’ when energized and ‘Off’ when de-energized.
Screen Change Diagnostics
Drive Coupling Extended
Front Screen Sensor
Centre Screen Sensor
Rear Screen Sensor
Exit Screen Sensor
Safety Screen Sensor
ON
ON
Home Screen Motor
Move Screen Motor Using Jog Buttons
Toggle Coupling Right
Toggle Coupling Left
Toggle Drive Coupling
Toggle Screen Clamps
Load Screen
Unload Screen
Read Barcode
ON
ON
ON
ON
ON
ON
ON
ON
Run
Diagnost
Next Previous Exit
