INFINITY
',$*1267,&6
5,6,1*7$%/(
Software Version 7 User Manual 5.29
Restore Default
Heights
Selecting this diagnostic function restores the vision height to the default of 50
mm and the print height to the default of 127 mm.
Set Reference
Vision Height
Selecting this diagnostic function enables the rising table vision height to be set
so that the camera views the board fiducials in focus. This is achieved by driving
the table up or down while viewing the vision monitor until the fiducial is in
focus. Pressing Calibrate Vision Height changes the menu Bar showing the
option Confirm. Pressing Confirm sets the current height of the rising table,
updating the printer configuration file. Refer to the Technical Reference Man-
ual, Camera and Vision System chapter for the camera reference position
procedure.
Set Reference Print
Height
Selecting this diagnostic function enables the print height to be set so that no gap
exists between the screen and board. Refer to the Technical Reference Manual,
Rising Table chapter for the print height calibration procedure.
Drive Table Using
Jog Buttons
Selecting this diagnostic function enables the right jog button to drive the rising
table up at slow speed and the left jog button to drive the table down, stopping
immediately the button is released.
Toggle Table Brake Selecting this diagnostic function alternately switches the table brake on and off,
while continuously displaying the current status.
Toggle Vacuum
Tooling Valve
Selecting this diagnostic function alternately switches the vacuum tooling sole-
noid on and off, to supply and remove pneumatic pressure to the venturi vacuum
pump, continuously displaying the current status.
Cycle Rising Table Selecting this diagnostic function first checks that the camera carriage is at the
home position, if not the rising table error message, ‘Table Movement Inhib-
ited, Camera Not Home’ is displayed. If the camera is in the home position, a
continuous cycle starts driving the rising table to print height, dwelling for two
seconds, driving the table down to its datum height, dwelling for two seconds
and repeating the cycle until Stop is pressed, or the Set Cycle Count has been
reached.
Rail Lifted Left This diagnostic function continuously displays the status of the rail lifted left
sensor. Off is displayed when the rail has been lifted.
Rail Lifted Right This diagnostic function continuously displays the status of the rail lifted right
sensor. Off is displayed when the rail has been lifted.
Table at Home This diagnostic function continuously displays the status of the home interlock
sensor. On is displayed when the rising table is in the home position.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
INFINITY
',$*1267,&6
08/7,,17(5)$&(81,7
5.30 User Manual Software Version 7
MULTI INTERFACE UNIT
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Toggle activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
NOTE
This diagnostic can only be run when the machine is connected to an upline and
downline machine.
Toggle Available A This diagnostic function is currently not used.
Toggle Upline A Selecting this diagnostic function sends a request to the upline machine to send
a board.
Toggle Downline A Selecting this diagnostic function sends a request to the downline machine to
receive a board.
Machine Available
A
This diagnostic function is currently not used.
Downline Ready A This diagnostic function continuously displays whether the downline machine
is ready to receive a board.
Upline Ready A This diagnostic function continuously displays whether the upline machine is
ready to send a board.
MIU Diagnostics
CLEAR
OFF
Machine Available A
Downline Ready A
Upline Ready A
Toggle
Available A
Upline A
Downline A
OFF
ON
CLEAR
SET
Toggle Next Previous Exit
INFINITY
',$*1267,&6
$872)/(;722/,1*67$1'$5'
Software Version 7 User Manual 5.31
AUTOFLEX TOOLING (STANDARD)
Selecting this diagnostics module opens the following window:
The menu bar changes displaying the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Tooling Pins Selecting this diagnostic function alternately lifts and lowers all the pins,
continuously displaying the current status.
Clamp Enable Selecting this diagnostic function alternately switches the electromagnet clamps
on or off, continuously displaying the current status. Any pins that are up when
the clamp is switched off automatically lower.
Clamp Power Selecting this diagnostic function alternately switches the power through the
electromagnetic coils between high and low, continuously displaying the current
status.
Autoflex Diagnostics
ON
Down
LO
Tooling Pins
Clamp Enable
Clamp Power
Change Pin Status
Cycle Autoflex Tooling
Run
Diagnost
Next Previous Exit
