INFINITY +286 (.( (3, 1* )($785( /,&(16,1 * Soft ware Ver sion 7 User Manual 7.25 FEA TURE LICENSING Intr oduction This standalone program accessed from the t askbar , enables a user to request and install a licenc…
INFINITY
+286(.((3,1*
5(&29(5<352&('85(
7.24 User Manual Software Version 7
16.Select OK, the following window is displayed:
17.Enter the machine serial number. In the Options box, select Dual Stepper
and the correct camera for the type fitted to the machine. Ensure Fixed Head
is not selected.
18.Select Next, the following window is displayed:
19.Insert the diskette containing the product and calibration data into A:drive
and press OK. The calibration data is now copied onto the machine hard
disk.
20.The machine now initializes.
21.The product files can now be copied onto the machine using Copy Data
function in Housekeeping (see Copy Data in Housekeeping Chapter).
Abort
Next
265 Option Selection
Options
Fixed Head
Machine Serial Number
Single Stepper
Dual Stepper
Green Pulnix
Green Sony
Grey Sony
Camera Type
ProFlow Print Carriage
273394
OK
Cancel
Insert disk containing Calibration data in driveA:
and press OK to load, or Cancel to Abort
265 Configuration
INFINITY
+286(.((3,1*
)($785(/,&(16,1*
Software Version 7 User Manual 7.25
FEATURE LICENSING
Introduction This standalone program accessed from the taskbar, enables a user to request and
install a licence to run a new feature on the machine. The opening window lists
all the licences available on the dongle and applicable to the machine. Each
licence enabled or requested is signified by a tick beside the feature listed. The
features available on the dongle are updated at software upgrades.
License Request 1. Select Start on the taskbar, Programs and Feature License. The following
window is displayed:
2. Select Customer Info. The following window is displayed:
Feature License
Version 01. 01. 01
GEM/SECS
Networking
620mm Boards
Basic Board Insp.
Advanced Board Insp.
Basic Stencil Insp.
Advanced Stencil Insp.
PC Type 1
PC Type 2
Customer Info
Print Features
Print Request
Install Licence
Refresh
Exit
Customer's Own Information
Company
Contact
Company Purchase Order Number
Another Company
1234567
01305 1234567
01305 7654321
Craig
Phone
Fax
Email
craig@another.com
Save
Cancel
INFINITY
+286(.((3,1*
)($785(/,&(16,1*
7.26 User Manual Software Version 7
3. Enter the information required and select Save. The information is written
to a ‘customer.txt’ file and attached to all licence request files, the window
is closed.
4. Scroll down the menu for the feature required. Select the feature, the
following window is displayed:
5. Select Yes , the following window is displayed:
6. Select Proceed, a request is written to the file indicated in the window. If
successful, the following window is displayed:
NOTE
If a different destination file is required for the licence request, press ...,
highlight the required file, select Open and Proceed.
7. The licence request.txt file can now be forwarded to your local DEK agent
for processing.
Yes
No
Do you want to obtain a licence to use
112731
on
620mm Boards
Feature Licensing
Feature Licence Request
Feature Licence Request
A request to licence the feature you have selected
will be written/appended to the above file.
A:\Request.txt
Proceed
Cancel
...
Request Generated
Feature Licensing
OK
