Software Version 7 User Manual 8.19

NOTE

If selecting a product file with site listings pre-loaded, a ‘Please Wait’

indicator bar may be displayed whilst all sites are being downloaded.

Edit Global 1. Select Edit Global.

NOTE

Delete Site is only available if at least one site exists already. Next Site and

Previous Site are only available if at least two sites exist already.

The following Edit Global Parameters window is displayed:

2. Enter the parameter values below using the Next, Previous, Incr. and Decr.

keys.

• Pre-images to Every

• Warning Limit to 20, this can be reduced later in ‘adjust inspect’

• Blockage Action to Manual Action, this can be changed later in ‘adjust

inspect’

• Smear Action to Manual Action, this can be changed later in ‘adjust

inspect’.

A definition of all 2Di parameters and their values is given at the end of this

chapter.

On completion of successful setup, parameters can be adjusted to suit the

product.

Edit

Global

Edit

Limits

Add

Site

Exit

ADVANCED

EVERY

MANUALACTION

MODE 1

MANUALACTION

MODE 2

MANUAL

DISABLED

STENCIL 2DI TYPE

BOARD 2DI TYPE

PRE-IMAGE MODE

MIN SITES/CYCLE

WARNING LIMIT

BLOCKAGE ACTION

BLOCKAGE CLEAN

SMEAR ACTION

SMEAR CLEAN

LOW PASTE ACTION

INSPECTAFTER CLEAN

Edit Global Parameters

NOTE: Advanced Inspection Type option is not available on some machines.

Limit

Options

Next Previous Incr. Decr. Exit

INFINIT

',163(&7,21

',163(&7,216(783

8.20 User Manual Software Version 7

3. Select Limit Options.

These are usually set to enabled. If for any reason a particular inspection

option is not required, set to disabled. If any global limit options are disabled

the corresponding limit sets and parameters are greyed out. These are global

limits, therefore they are active for the whole product. If a particular

inspection is not required for a specific type of site, this can be achieved later

in limit set options for the site.

4. Enter global limit options using Next, Previous, Incr. and Decr. keys.

5. Select Exit.

6. Select Exit.

Limit

Options

Next Previous Incr. Decr. Exit

Global Limit Set Options

Blockage

Smear

Paste

Alignment

Bridging

Volume

Enabled

Next Previous Incr. Decr. Exit

Limit

Options

Next Previous Incr. Decr. Exit

INFINITY

',163(&7,21

',163(&7,216(783

Software Version 7 User Manual 8.21

Edit Limit Set 1. Select Edit Limits.

NOTE

Some buttons in the menu bar above may not be shown, depending if sites

already exist.

The following window is displayed:

Limit sets list the different sets of limit parameters that are available, initially

only default is available. Limit parameters list the current limits for the

highlighted limit set.

2. At this point either:

a. Add limits to create a new limit set, continue with Add Limits below.

b. Edit limits to edit an existing limit set, go to the Edit Limits section.

NOTE

It is recommended that during setup, parameters are set at a level that no

alarms occur (coarse). Once the inspection is correctly setup, the parame-

ters can be tightened during production in ‘adjust inspect’.

Add Limits 1. Select Add Limits.

NOTE

Next limit and previous limit are only available if at least one limit, plus the

default, exist already.

Edit

Global

Edit

Limits

Delete

Site

Edit

Site

Inspect

Site

Exit

Default

10%

15%

0.01 sq mm

0.15 sq mm

90%

80%

0.02mm

0.03mm

0.05mm

0.04mm

80%

70%

LimitSetID

BlockageWarning

BlockageAlarm

SmearWarning

SmearAlarm

PasteWarning

PasteAlarm

AlignWarning

AlignAlarm

BridgeWarning

BridgeAlarm

VolumeWarning

VolumeAlarm

LimitSets

LimitParameters

Add

Limits

Edit

Limits

Limit

Exit
