INFINITY
',163(&7,21
237,216$)7(5$1,163(&7,21$/$50
Software Version 7 User Manual 8.37
OPTIONS AFTER AN INSPECTION ALARM
The machine stops at the first inspection alarm. When an inspection alarm
occurs, several menu bar options become available.
The functional description for each option is as follows:
Accept Selecting this option clears the alarm panel, changes the beacon back to green
and feeds the board through the machine.
Inspect More Selecting this option clears the alarm panel, changes the beacon back to green
and allows the inspection sequence to continue, until it either completes inspec-
tion or raises another alarm.
Recovery Action Selecting this option displays the following menu:
The user prompt text shows the following lines:
‘Clean Mode 1 : XXXX’
‘Clean Mode 2 : YYYY’
Where XXXX and YYYY are the descriptions of the clean mode settings, ie
‘WVWD’ for wet, vac, wet, dry.
Paste Load Selecting this option initiates a paste load cycle, if a paste dispenser is fitted or
enables paste to be loaded manually.
Clean Mode 1 and 2 Selecting either clean mode 1 or clean mode 2 initiates the screen clean cycle set
up for that mode.
Re-print Board Selecting this option clears the alarm panel and changes the beacon back to
green. The board is re-printed and the inspection sequence is started again from
the beginning. All the existing alarm information is cleared.
NOTE
The Re-print Board button is not available if the current board has already been
re-printed.
Adjust Selecting this option allows the adjustment of process parameters.
Inspect All Selecting this option clears the alarm panel and changes the beacon back to
green. The inspection sequence is restarted from the beginning. All the existing
alarm information is cleared.
Adjust Inspect Selecting this option displays the following menu:
Accept
Inspect
More
Recovery
Action
Adjust
Inspect
All
Adjust
inspect
Reject
Paste
Load
Clean
Mode 1
Clean
mode 2
Re-print
Board
Exit
Edit
Global
Edit
Limits
New Pre-
images
Edit
Site
Inspect
Site
Exit
INFINIT
Y
',163(&7,21
237,216$)7(5$1,163(&7,21$/$50
8.38 User Manual Software Version 7
Edit Global Selecting this option opens the edit global parameters window, allowing param-
eters that are used throughout the inspection to be altered.
Edit Limits Selecting this option opens the limit sets window, allowing a set of limit
parameters to be selected and altered.
New Pre-images Selecting this option initiates a pre-print inspection on the next print cycle to
capture the new pre-images. The message ‘New pre-images will be collected
next print cycle’ is displayed.
NOTE
The New Pre-image button is only available if pre-image is set to 1.
Edit Site Selecting this option opens the site parameters window, allowing adjustment of
the site specific parameters.
Inspect Site Selecting this option opens the inspection results window and displays the
following menu:
Selecting Next or Previous moves the highlight up and down the list of site pads.
Selecting Toggle Paste either shows or hides the paste display overlay onto the
monitor. The toggle paste facility on the board image is only functional with the
board inspection type set to advanced. Toggling paste on the screen is only
available on Horizon and Infinity machines and only with the stencil inspect type
set to basic or advanced.
Selecting Auto Scale automatically adjusts the paste scaling value for the
current site, to cause the value of paste present, on the pad currently selected in
the inspection result list, to be reported as 100%. This is used where the site pad
causing the alarm is actually a good print.
Reject Selecting this option clears the alarm panel and the board is fed to the output end
of the rail system and held there.
Auto
Scale
Toggle
Paste
Next Previous Exit
INFINITY
',163(&7,21
0(183$5$0(7(56
Software Version 7 User Manual 8.39
MENU PARAMETERS
2D Inspect Rate This parameter sets the number of print cycles between inspection cycles, with
zero indicating no inspection.
Stencil Inspect
Type
This parameter sets the extent of the stencil inspection. The options are:
Board Inspect Type This parameter sets the type of inspection to be learnt:
Pre-image This parameter sets when a pre-image is taken. The options are:
Min Sites/Cycle This parameter sets the number of sites to inspect every cycle.
Warning Limit This parameter determines how many consecutive warnings on the same site
constitute an alarm.
Blockage Action This parameter sets the action performed on a blockage alarm. The options are:
Blockage Clean This parameter sets the type of screen clean performed on blockage alarm. The
options are:
Smear Action This parameter sets the action performed on a smear alarm. The options are:
Minimum Maximum Increments
01001
None Basic Advanced
None Basic Advanced
One - First Board Only Every - Every Board
Minimum Maximum Increments
Number of Every Cycle sites plus one, ie at least
one general site must be inspected
Total number of sites 1
Minimum Maximum Increments
1201
Manual Automatic
Mode 1 Mode 2
Manual Action Automatic
