INFINITY ',163(& 7,21 0(18 3$5$ 0(7 (56 Soft ware Ver sion 7 User Manual 8.39 MENU P ARAM ETERS 2D Inspect Rate This para meter sets the number of print cycle s between inspection cycles, with zero indicating…
INFINIT
Y
',163(&7,21
237,216$)7(5$1,163(&7,21$/$50
8.38 User Manual Software Version 7
Edit Global Selecting this option opens the edit global parameters window, allowing param-
eters that are used throughout the inspection to be altered.
Edit Limits Selecting this option opens the limit sets window, allowing a set of limit
parameters to be selected and altered.
New Pre-images Selecting this option initiates a pre-print inspection on the next print cycle to
capture the new pre-images. The message ‘New pre-images will be collected
next print cycle’ is displayed.
NOTE
The New Pre-image button is only available if pre-image is set to 1.
Edit Site Selecting this option opens the site parameters window, allowing adjustment of
the site specific parameters.
Inspect Site Selecting this option opens the inspection results window and displays the
following menu:
Selecting Next or Previous moves the highlight up and down the list of site pads.
Selecting Toggle Paste either shows or hides the paste display overlay onto the
monitor. The toggle paste facility on the board image is only functional with the
board inspection type set to advanced. Toggling paste on the screen is only
available on Horizon and Infinity machines and only with the stencil inspect type
set to basic or advanced.
Selecting Auto Scale automatically adjusts the paste scaling value for the
current site, to cause the value of paste present, on the pad currently selected in
the inspection result list, to be reported as 100%. This is used where the site pad
causing the alarm is actually a good print.
Reject Selecting this option clears the alarm panel and the board is fed to the output end
of the rail system and held there.
Auto
Scale
Toggle
Paste
Next Previous Exit
INFINITY
',163(&7,21
0(183$5$0(7(56
Software Version 7 User Manual 8.39
MENU PARAMETERS
2D Inspect Rate This parameter sets the number of print cycles between inspection cycles, with
zero indicating no inspection.
Stencil Inspect
Type
This parameter sets the extent of the stencil inspection. The options are:
Board Inspect Type This parameter sets the type of inspection to be learnt:
Pre-image This parameter sets when a pre-image is taken. The options are:
Min Sites/Cycle This parameter sets the number of sites to inspect every cycle.
Warning Limit This parameter determines how many consecutive warnings on the same site
constitute an alarm.
Blockage Action This parameter sets the action performed on a blockage alarm. The options are:
Blockage Clean This parameter sets the type of screen clean performed on blockage alarm. The
options are:
Smear Action This parameter sets the action performed on a smear alarm. The options are:
Minimum Maximum Increments
01001
None Basic Advanced
None Basic Advanced
One - First Board Only Every - Every Board
Minimum Maximum Increments
Number of Every Cycle sites plus one, ie at least
one general site must be inspected
Total number of sites 1
Minimum Maximum Increments
1201
Manual Automatic
Mode 1 Mode 2
Manual Action Automatic
INFINIT
Y
',163(&7,21
0(183$5$0(7(56
8.40 User Manual Software Version 7
Smear Clean This parameter sets the type of screen clean performed on a smear alarm. The
options are:
Low Paste Action This parameter sets the action performed on a low paste alarm. The options are:
Inspect After Clean This parameter sets whether the stencil is inspected before the next board is
printed following a screen clean. The options are:
No. Sites This parameter displays the total number of sites.
Site Name The unique name given to a site for identification. The name can have a
maximum of 20 characters.
Site Priority This parameter determines the priority of a site. Where the site is part of a
device, the value applies to the whole device. The options are:
NOTE
If the machine inspection page is set to GUI 2Di, all displayed sites are coloured
coded, depending on their priority setting, (following table refers):
Site Alignment This parameter sets what alignment data is reported for each site. The options
are:
Limit Set ID The unique name given to a set of limits which can be applied to any site. This
enables different sites to be inspected according to different limits. The name
can have a maximum of 20 characters. A maximum of 14 limit sets can be
created.
Mode 1 Mode 2
Manual Re-print
Disabled Enabled
Minimum Maximum Increments
010001
Not Inspected General Every Cycle
Site Priority Display Colour
Every Cycle
Green
General
Yellow
Not Inspected
Blue
X & Y X Only Y Only None
