INFINITY &21680$ %/(5(3/ (1,6+0(1 76 3$67(/2$ ',1* 9.8 User Manual Software Version 7 8. If the set pre ference is set to pause , see a. If the set prefere nce is set set to suspend, see b. a. The tricoloured …

100%1 / 356
INFINITY
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
Software Version 7 User Manual 9.7
7. Press Exit (F8).
8. Press Exit (F8).
Dispensing Paste at
Random Intervals
The operator can cycle the paste dispenser at random intervals and before a print
run in addition to any preprogrammed cycles.
To load paste prior to a print run:
1. Press Paste Load (F3).
2. Press Auto Dispense (F1).
3. If the paste dispenser has sufficient paste the dispenser carries out an
automatic dispense, go to Step 13. If the paste dispenser is low on paste a
warning window is displayed. The warning window varies, depending on
the setting of the consumable action option in set preferences. If the set
preference is set to warn, continue with Step 4. If the set preference is set to
pause or suspend go to Step 8.
4. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
5. Select Confirm (F1).
6. To replace the paste cartridge carry out the Fitting a New Paste Cartridge
procedure, later in this section.
7. Repeat Steps 1, 2 and 13.
Save Next Previous Incr. Decr. Exit
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
Auto
Dispense
Manual
Load
Load
Cart.
Print
Directn
Exit
Warning
Print Medium Low. Please replenish.
Confirm
INFINITY
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
9.8 User Manual Software Version 7
8. If the set preference is set to pause, see a. If the set preference is set set to
suspend, see b.
a. The tricoloured beacon shows red and the following window and menu bar
is displayed:
b. The tricoloured beacon shows red and the following window and menu bar
is displayed:
9. Select Refill Paste (F1). The message ‘Select Load Cart to load the
cartridge or exit to abort.’ is displayed.
NOTE
If either the under screen cleaner paper or solvent are low or the Vortex
cleaning cassette has expired and are reported first, the refill paste option is
not displayed. In this case select Cancel until Refill Paste is displayed in the
menu bar.
10.Select Load Cart. (F1). The print carriage drives to the front of the machine
and the dispenser rises to the vertical position. A message is displayed on
the screen ‘Open Cover and Replace Paste Cartridge’.
11. To replace the paste cartridge carry out Steps 3-10 of Fitting a New Paste
Cartridge procedure, later in this section.
12.Repeat Steps 1, 2 and 13.
13.After the dispense routine has been completed, press Exit (F8).
Pause on Warning
Print Medium Low. Please replenish.
Refill
Paste
Cancel
Suspend on Warning
Print Medium Low. Please replenish.
Refill
Paste
Cancel
Refill
Paste
Cancel
Load
Cart.
Exit
Auto
Dispense
Manual
Load
Load
Cart.
Print
Directn
Exit
INFINITY
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
Software Version 7 User Manual 9.9
To Load Paste
During a Print Run
1. Press Paste Load (F3).
2. Press Auto Dispense (F1).
3. If the paste dispenser has sufficient paste the dispenser carries out an
automatic dispense, go to Step 22. If the paste dispenser is low on paste a
warning window is displayed. The warning window varies, depending on
the setting of the consumable action option in set preferences. If the set
preference is set to warn, continue with Step 4. If the set preference is set to
pause go to Step 10. If the set preference is set to suspend go to Step 16.
4. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
5. Select Confirm (F1).
6. Select End Run (F1).
7. To replace the paste cartridge carry out Fitting a New Paste Cartridge
procedure, later in this section.
8. Select Run (F1).
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Auto
Dispense
Manual
Load
Load
Cart.
Print
Directn
Exit
Warning
Print Medium Low. Please replenish.
Confirm
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
