11. Press Exit (F8).
Paper and Solvent
Replenishment
Paper and solvent replenishment can take place with the cleaner unit in the
printer. When paper or solvent needs replenishment a warning window is
automatically displayed on the monitor. The warning window varies, depending
on the setting of the consumable action option in set preferences. The message
in the warning window depends on whether the solvent or paper or both require
replenishment. The procedure varies, depending on whether the replenishment
is prior to a print run or during a print run.
Replenishment Prior to a Print Run:
If the set preference is set to warn, continue with Step 1. If the set preference is
set to pause or suspend go to Step 4.
1. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
2. Select Confirm (F1).
3. Go to Step 17.
4. If the set preference is set to pause, the tricoloured beacon shows red and the
following window and menu bar is displayed:
If the set preference is set to suspend, the tricoloured beacon shows red and
the following window and menu bar is displayed:
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Warning
Cleaner paper Low. Please replace.
Confirm
Pause on Warning
Cleaner Solvent Low. Please refill.
Cancel
Suspend on Warning
Cleaner Solvent Low. Please refill.
Cancel
INFINITY
&21680$%/(5(3/(1,6+0(176
%/8(81'(56&5((1&/($1(5
Software Version 7 User Manual 9.19
5. Select Cancel (F8).
6. Go to Step 17.
Replenishment During a Print Run:
If the set preference is set to warn, continue with Step 7. If the set preference
is set to pause go to Step 11. If the set preference is set to suspend go to Step
15.
7. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
8. Select Confirm (F1).
9. Select End Run (F1).
10.Go to Step 17.
11. If the set preference is set to pause, the tricoloured beacon shows red and the
following window is displayed:
12.Select Defer (F8). The print run continues.
13.Select End Run (F1).
14.Go to Step 17.
Cancel
Warning
Cleaner paper Low. Please replace.
Confirm
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Pause on Warning
Cleaner Solvent Low. Please refill.
Defer
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
INFINITY
&21680$%/(5(3/(1,6+0(176
%/8(81'(56&5((1&/($1(5
9.20 User Manual Software Version 7
15.If the set preference is set to suspend, the tricoloured beacon shows red and
the following window is displayed:
16.Select End Run (F8).
17.Press Head (F2). The message ‘Raise Head using 2-button Control’ is
displayed.
18.Raise the printhead using two button control.
19.Fit the head prop.
20.Press Confirm (F1).
Solvent Replenishment
WARNING
RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST COMPLY WITH
LOCAL ENVIRONMENTAL GUIDELINES. DEK RECOMMEND USING SOLVENTS
THAT ARE ENVIRONMENTALLLY FRIENDLY, IE CFC FREE AND WATER BASED.
SOLVENTS USED MUST HAVE FAST EVAPORATION RATES AND FLASHPOINT
SPECIFICATIONS GREATER THAN 39ºC.
WARNING
SOLDER PASTE AND SOLVENTS. WHEN USING OR HANDLING ANY SOLDER
PASTE OR SOLVENT FORMULATION THE MANUFACTURERS’ RECOMMEND
SAFETY PRECAUTIONS MUST BE STRICTLY ADHERED TO.
WARNING
PROTECTIVE CLOTHING. APPROVED PROTECTIVE CLOTHING SHOULD BE
WORN BY SOLDER PASTE AND SOLVENT HANDLERS AT ALL TIMES TO
ELIMINATE FUME INHALATION, EYE CONTACT, SKIN CONTACT AND
INGESTION.
WARNING
SOLVENT SOLUTION. DO NOT MIX SOLVENT SOLUTIONS. FLUSH THE
SOLVENT TANK THOROUGHLY WHEN CHANGING TO A DIFFERENT SOLVENT
SOLUTION.
WARNING
SOLVENT SPRAY. THE UNDERSCREEN CLEANER SPRAYS A FINE JET OF
SOLVENT SOLUTION ON TO THE CLEANER. APPROVED PROTECTIVE
CLOTHING SHOULD BE WORN.
