INFINITY
&21680$%/(5(3/(1,6+0(176
9257(;81'(56&5((1&/($1(5
Software Version 7 User Manual 9.31
6. Press Save (F2) on completion of parameter setup.
7. Press Exit (F8).
8. Press Exit (F8).
Cleaning Cassette
and Solvent
Replenishment
The cleaning cassette and solvent replenishment can take place with the cleaner
unit in the printer. When the cleaning cassette or solvent needs replenishment a
warning window is automatically displayed on the monitor. The warning
window varies, depending on the setting of the consumable action option in set
preferences. The message in the warning window depends on whether the
cleaning cassette or solvent or both require replenishment. The procedure
varies, depending on whether the replenishment is prior to a print run or during
a print run.
Replenishment Prior to a Print Run:
If the set preference is set to warn, continue with Step 1. If the set preference is
set to pause or suspend go to Step 4.
1. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
2. Select Confirm (F1).
3. Go to Step 17.
Save Next Previous Incr. Decr. Exit
Save Next Previous Incr. Decr. Exit
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Warning
Vortex cleaning cassette expired. Please replace.
Confirm
INFINITY
&21680$%/(5(3/(1,6+0(176
9257(;81'(56&5((1&/($1(5
9.32 User Manual Software Version 7
4. If the set preference is set to pause, the tricoloured beacon shows red and the
following window and menu bar is displayed:
If the set preference is set to suspend, the tricoloured beacon shows red and
the following window and menu bar is displayed:
5. Select Cancel (F8).
6. Go to Step 17.
Replenishment During a Print Run:
If the set preference is set to warn, continue with Step 7. If the set preference is
set to pause go to Step 11. If the set preference is set to suspend go to Step 15.
7. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
8. Select Confirm (F1).
9. Select End Run (F1).
10.Go to Step 17.
Pause on Warning
Vortex cleaning cassette expired. Please replace.
Cancel
Suspend on Warning
Vortex cleaning cassette expired. Please replace.
Cancel
Cancel
Warning
Vortex cleaning cassette expired. Please replace.
Confirm
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
INFINITY
&21680$%/(5(3/(1,6+0(176
9257(;81'(56&5((1&/($1(5
Software Version 7 User Manual 9.33
11. If the set preference is set to pause, the tricoloured beacon shows red and the
following window is displayed:
12.Select Defer (F8). The print run continues.
13.Select End Run (F1).
14.Go to Step 17.
15.If the set preference is set to suspend, the tricoloured beacon shows red and
the following window is displayed:
16.Select End Run (F8).
17.Press Head (F2). The message ‘Raise Head using 2-button Control’ is
displayed.
18.Raise the printhead using two button control.
19.Fit the head prop.
20.Select Confirm (F1).
Pause on Warning
Vortex cleaning cassette expired. Please replace.
Defer
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Suspend on Warning
Vortex cleaning cassette expired. Please replace.
End
Run
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
Confirm
