INFINITY
&21680$%/(5(3/(1,6+0(176
648((*((6
9.38 User Manual Software Version 7
SQUEEGEES
Fitting the
Squeegees
From the status page:
1. Press Setup (F6).
2. Press Setup Squeegee (F4).
3. Press Change Squeegee (F1). The message ‘Open cover and change
squeegees’ is displayed.
4. Open the front printhead cover.
The front and rear squeegees must be fitted in the correct positions. Each
squeegee has a key-way machined into it to ensure that it cannot be incor-
rectly fitted.
5. Fit the rear squeegee onto the rear squeegee mount tightening the thumb-
screws until they are finger tight.
6. Fit the front squeegee onto the front squeegee mount again ensuring that the
thumbscrews are only finger tight.
7. Close the front printhead cover.
8. Press the System button.
9. Press Continue (F1).
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Change
Squeegee
Calibrat
Heights
Exit
Continue
INFINITY
&21680$%/(5(3/(1,6+0(176
648((*((6
Software Version 7 User Manual 9.39
10.Press Calibrat Heights (F2). The message ‘Remove Screen Before Com-
mencing Pressure Calibration!’ is displayed.
11. Press Exit (F8).
12.Press Change Screen (F5). The message ‘Remove Screen’ is displayed.
13.Open the front printhead cover.
14.Remove the screen.
15.Close the front printhead cover.
16.Press the System button.
17.Press Setup Squeegee (F4).
18.Press Calibrat Heights (F2). The message ‘Ensure that the Correct
Squeegees are fitted ’is displayed.
19.Press Continue (F1). The message ‘Calibrating Pressure Heights - DO
NOT Open Covers!’ is displayed.
20.Press Exit (F8).
21.Press Exit (F8).
Change
Squeegee
Calibrat
Heights
Exit
Change
Squeegee
Calibrat
Heights
Exit
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Change
Squeegee
Calibrat
Heights
Exit
Continue
Restore
Defaults
Exit
Change
Squeegee
Calibrat
Heights
Exit
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
INFINITY
&21680$%/(5(3/(1,6+0(176
352)/2:
9.40 User Manual Software Version 7
PROFLOW
Introduction This Section details the various procedures for the replenishment of the ProFlow
unit. A separate ‘Best Working Practices’ guide is also available, detailing
common procedures for the replenishment, housekeeping and maintenance of
ProFlow transfer heads (DEK Part No.171280). It is recommended that the Best
Working Practices guide is used in conjunction with any of the following
replenishment procedures.
NOTE
ProFlow Best Working Practices Manuals can be ordered online at
http://www.dek.com or email spares@dek.com quoting DEK Part No.171280.
ProFlow Cassette
Change
It is necessary at intervals to fit a new ProFlow cassette into the ProFlow transfer
head. If the cassette is empty at the end of a print stroke, the warning window
‘Print Medium Low. Please Replenish.’ is displayed.
WARNING
SOLDER PASTE AND SOLVENTS. WHEN USING OR HANDLING ANY SOLDER
PASTE OR SOLVENT FORMULATION THE MANUFACTURERS’ RECOMMEND
SAFETY PRECAUTIONS MUST BE STRICTLY ADHERED TO.
WARNING
PROTECTIVE CLOTHING. APPROVED PROTECTIVE CLOTHING SHOULD BE
WORN BY SOLDER PASTE AND SOLVENT HANDLERS AT ALL TIMES TO
ELIMINATE FUME INHALATION, EYE CONTACT, SKIN CONTACT AND
INGESTION.
NOTE
When using a ProFlow transfer head for the first time or if the transfer head
conditioning chamber has been cleaned, ie free from solder paste. The condi-
tioning chamber must be primed first with the print medium. Two ProFlow
cassettes are required, the first ProFlow cassette is used to prime the condition-
ing chamber. The second ProFlow cassette is fitted ready for machine opera-
tion.
The ProFlow cassette can be fitted or changed prior to and during a print run.
Prior to a Print Run The ProFlow cassette can be fitted or changed prior to selecting Run.
1. If ProFlow is in the home position continue from Step 2. If ProFlow is in the
contact position go to Step 19.
2. Select Setup (F6).
3. Select Setup ProFlow (F4).
4. Select Load Cassette (F4). The message ‘Has the ProFlow unit’s base
cover been removed?’ is displayed.
Run Head
Knead
Paste
Clean
Screen
Adjust Setup Monitor Maint.
Mode
Load
Data
Edit
Data
Setup
ProFlow
Change
Screen
Change
Tooling
Change
Language
Exit
Change
ProFlow
Load
Cassette
Prime
ProFlow
Exit
