INFINITY
&21680$%/(5(3/(1,6+0(176
352)/2:
9.58 User Manual Software Version 7
If the Unload Board Start in Set Preferences is set to Separation, the follow-
ing window and menu bar is displayed:
Selecting Continue Run clears the warning window and the print cycle
continues.
Selecting End Run clears the warning window, the print cycle is aborted and
control is returned to the ready page.
NOTE
If Camera Idle Position is set to Behind Rail and Unload Board Start is set
to Separation, the warning windows appear one after the other in the order
shown above.
The machine carries out a print cycle, the ProFlow unit moves to the rear of
the image.
22.When the ProFlow unit is at the rear of the image, select End Run (F1).
23.Open the front printhead cover.
24.Ensure that the ProFlow pressure mechanism is in the raised position (to
expose transfer head diaphragm).
Unload Board Speedup Warning
The UNLOAD BOARD SPEEDUP option is set to
'Separation'
With this option enabled it should be noted
that there is only a minimal clearance
between the underside of the board and any
tooling being used, while the board is being
unloaded.
This option must not be used for boards that
are populated on the underside, as this
could damage the boards.
Continue
Run
End
Run
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
INFINITY
&21680$%/(5(3/(1,6+0(176
352)/2:
Software Version 7 User Manual 9.59
25.Remove the centre filling port bayonet cap.
26. Using either a general purpose mastic gun or the optional ProFlow pneumatic
gun. Load a standard cartridge and fit the short recharging nozzle to the
cartridge, (figure below refers).
NOTE
Ensure that any air within the cartridge and nozzle is expelled prior to using
the gun, ie charge the gun so that paste is starting to exude from the nozzle
(figure below refers).
27.Push the nozzle of the gun into the centre filling port of the ProFlow transfer
head (see figure below).
Filling Port
Bayonet Cap
Diaphragm
Diaphragm Retainer
Recharging Nozzles
Filling Port
Bayonet Cap
Filling Port
Bayonet Cap
Transfer Head (Showing Diaphragm)
Short Recharging Nozzle
INFINITY
&21680$%/(5(3/(1,6+0(176
352)/2:
9.60 User Manual Software Version 7
28.Slowly fill the diaphragm until it starts to balloon, smooth the top of the
diaphragm so that the paste is evenly dispersed along its length.
29.Alternatively, fill using all three filling ports for even distribution.
NOTE
Ensure that only one port is opened at a time.
30.Do not overfill. If this occurs any excess will seep out between the wipers
and the screen.
NOTE
Clean any excess seepage before commencing print operations.
31.Ensure that the threaded areas around the filling ports are thoroughly clean
before commencing print operation.
32.Refit the port bayonet caps.
33.Close the front printhead cover.
34.Press the System button.
During a Print Run When the transfer head needs replenishing a warning window is automatically
displayed on the monitor. The warning window varies, depending on the setting
of the consumable action in set preference.
If the set preference is set to warn, continue with Step 1. If the set preference is
set to pause go to Step 6. If the set preference is set to suspend go to Step 13.
1. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
2. Select Confirm (F1).
3. Select End Run (F1), when the ProFlow unit is at the rear of the image..
4. Carry out Steps 23-34 of Prior to a Print Run procedure, earlier in this
section.
5. Select Run (F1).
Warning
Print Medium Low. Please replenish.
Confirm
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
