INFINITY 0$&+,1( 352*5$ 00,1* 67$*( ',6 (783 1.84 User Manual Software Versi on 7 ST AGE 9 - 2DI SETUP For a complete explanation of 2D inspecti on and its setup refer to the 2D Inspection chapter of thi…
INFINITY
0$&+,1(352*5$00,1*
67$*(35,17,167(302'(
Software Version 7 User Manual 1.83
7. Select Step (F1).
8. Select Step (F1)
9. Select Step (F1)
10.Select Step (F1)
11. Select Auto Board (F1)
12.Remove the board from the conveyor and inspect the print for alignment. If
the alignment is satisfactory go to Step 16, if the alignment needs adjusting,
calculate the following:
X Offset, Y Offset and θ Offset.
13.Select Edit Data (F3)
14.Enter the X Offset, Y Offset and θ Offset, calculated in Step 12 to both the
Forward and Reverse set of offsets.
15.Repeat Steps 1-12 until the alignment is correct for both a forward and
reverse print.
16.If 2D Inspection is being used continue with Stage 9, if 2D Inspection isn’t
being used go to Stage 10.
Step Head
Fiducial
Setup
Adjust
Search
Step
Search
Reset
Single Exit
Step Head
Fiducial
Setup
Adjust
Search
Step
Search
Reset
Single Exit
Step Head
Fiducial
Setup
Adjust
Search
Step
Search
Reset
Single Exit
Step
Inspect
setup
Single Exit
Auto
Board
Manual
Board
Single Exit
Auto
Adjust
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
INFINITY
0$&+,1(352*5$00,1*
67$*(',6(783
1.84 User Manual Software Version 7
STAGE 9 - 2DI SETUP
For a complete explanation of 2D inspection and its setup refer to the 2D
Inspection chapter of this manual.
INFINITY
0$&+,1(352*5$00,1*
67$*(35,17,158102'(
Software Version 7 User Manual 1.85
STAGE 10 - PRINT IN RUN MODE
1. Select Setup (F6).
2. Select Mode (F1) until Auto is indicated in the mode option on the screen.
3. Select Exit (F8).
4. Select Run (F1).
If the Camera Idle Position in Set Preferences is set to Behind Rail, the
following window and menu bar is displayed:
Selecting Continue Run clears the warning window and the print cycle
continues.
Selecting End Run clears the warning window, the print cycle is aborted and
control is returned to the ready page.
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
Camera Behind Rail Warning
The CAMERA HOME POSITION is set to 'Behind
Rail'
Ensure that no tooling pins or other
obstructions are on the table behind the
rear rail, as these could cause damage to
the camera.
This option will only have an effect for
boards that are less than 250mm wide.
This option can be disabled from the set
preference page.
Continue
Run
End
Run
