Mesh Front This parameter sets the distance between the inner edge of the screen frame and
the screen glue line at the front of the frame. It defines the area that should not
be contacted by the squeegees/ProFlow.
Mesh Rear This parameter sets the distance between the inner edge of the screen frame and
the screen glue line at the rear of the frame. It defines the area that should not be
contacted by the squeegees/ProFlow.
Mesh Left This parameter sets the distance between the inner edge of the screen frame and
the screen glue line at the left of the frame. It defines the area that should not be
contacted by the squeegees/ProFlow.
Mesh Right This parameter sets the distance between the inner edge of the screen frame and
the screen glue line at the right of the frame. It defines the area that should not
be contacted by the squeegees/ProFlow.
Image X This parameter defines the dimension in the X axis from the right inner edge of
the screen frame to either:
Right hand edge of the image - right justified image
Left hand edge of the image - left justified image
Centre line of the image - centre justified image
Image Y This parameter defines the dimension in the Y axis from the front inner edge of
the screen frame to either:
Front edge of the image - front justified image
Rear edge of the image - rear justified image
Centre line of the image - centre justified image
Minimum Maximum Increment Default
0.0mm Screen Length - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Screen Length - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Screen Width - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Screen Width - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
60.0mm Screen Length - 100.0mm 0.1mm 330.4mm
Minimum Maximum Increment Default
60.0mm Screen Width - 100.0mm 0.1mm 330.4mm
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.91
Image X
Justification
This parameter defines the position of the image about the Image X parameter.
The image can be left, right or centre justified about Image X. Options are:
Image Y
Justification
This parameter defines the position of the image about the Image Y parameter.
The image can be front, rear or centre justified about Image Y. Options are:
Barcode Y This parameter defines the dimension between the centre of the barcode to the
outer rear edge of the screen frame or adaptor.
Screen Adapter The type of screen adapter needed, if any, for the screen to be used for this
product.
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Screen Image The position of the image in the screen frame. Options are:
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Option Default
Left Centre
Right
Centre
Option Default
Front Centre
Rear
Centre
Minimum Maximum Increment Default
10.0mm Screen Length - 10.0mm 0.1mm 97.0mm
Options Available
None
255
Sanyo
Heraeus
20 X 20
12 X 12
Options Available Notes
Edge Justified Permitted for Sanyo and Fuji frames only
Centre Justified -
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.92 User Manual Software Version 7
Custom Screen This option allows user definable screen image positions. Selection of this
parameter activates the Print Area Length, Print Area Width and Distance To
Image. Options are:
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Distance to Image The meaning of this parameter varies, depending on whether an image is centre
or edge justified. For centre justified images, the dimension is the distance from
the outside rear of the screen frame to the centre of the image. For edge justified
images, the dimension is the distance from the outside rear of the screen frame
to the front edge of the board.
NOTE
This parameter field only appears if Custom Screen has been selected.
Print Area Length This is the maximum printable distance in the Y direction, ie the maximum
distance the squeegee can travel, front to back.
NOTE
This parameter field only appears if Custom Screen has been selected.
Print Area Width This is the maximum length of squeegee that could be fitted to the printer, taking
into account screen frame and the amount of mesh surrounding the mask. This
is also the maximum length of paste that can be dispensed.
NOTE
This parameter field only appears if Custom Screen has been selected.
Options Available
Enabled
Disabled
Minimum Maximum Increment
306.0mm 645.0mm 0.1mm
Minimum Maximum Increment
100.0mm 508.5mm 0.1mm
Minimum Maximum Increment
100.0mm 510.0mm 0.1mm
