2 STINGER, A GUIDE TO ADHESIVE DOT DISPENSING
2.1 WARNING, MANDATORY AND SAFETY NOTICES
GUIDE TO ADHESIVE DOT DISPENSING STINGER 03/2021 7
2 STINGER, A GUIDE TO ADHESIVE DOT DISPENSING
2.1 WARNING, MANDATORY AND SAFETY NOTICES
2.1.1 Warning Notices
Safety notices in the form of WARNING, MANDATORY and SAFETY labels are placed on the
printing machine, and where appropriate, on the fitted option. Notices are posted throughout the
associated documentation, to alert operators/maintainers to possible hazards, which may cause
physical injury or equipment damage.
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
CAUTION
EQUIPMENT SERVICING. THE LASER/LED DOES NOT CONTAIN USER
SERVICEABLE PARTS. OPENING THE UNIT COULD CAUSE MIS-ALIGNMENT
OF THE LASER, THIS MAY MAKE THE EQUIPMENT DANGEROUS TO
OPERATE.
2.1.2 Mandatory Notices
Mandatory notices draw the attention of operators/maintainers to the prescribed behaviour to be
adhered whilst engaged in the activity. The following mandatory labels are affixed to the machine
and are displayed in the machine documentation:
MANDATORY
TOXIC SUBSTANCES MAY BE PRESENT. SAFETY GLOVES MUST BE WORN.
MANDATORY
TOXIC SUBSTANCES MAY BE PRESENT. EYE PROTECTION MUST BE WORN.
2.1.3 Equipment Specific Safety Notices
Where an option could represent a potential hazard, labels are attached in appropriate places on
the equipment, and are identified in the relevant area of the manual.
LASER RADIATION
DO NOT STARE IN TO BEAM
Wavelength: 620 . . . . 680nm
Max. av. Output: <1mW
IEC 60825 - 1, Ed, 2, 2007
CLASS 2 LASER PRODUCT
Complies with 21CFR 1040.10 and 1040.11
except for deviations pursuant to laser notice
No. 50. dated July 26. 2001
June 24. 2007
2 STINGER, A GUIDE TO ADHESIVE DOT DISPENSING
2.1 WARNING, MANDATORY AND SAFETY NOTICES
8 GUIDE TO ADHESIVE DOT DISPENSING STINGER 03/2021
2.1.4 Compliance Labels
Compliance labels may also be fitted to indicate the company, country and date of manufacture.
Manufacturer: Techc n
Address: 12151 Monarch Street,
Garden Grove,
CA. 92841
Country of Manufacture: USA
Manufacture Date:
Month Year
Complies with 21CFR1040 with
deviations pursuant to Laser Notice 50.
SYSTEMS
2.1.5 Equipment Label Locations
LASER RADIATION
DO NOT STARE IN TO BEAM
Wavelength: 620 . . . . 680nm
Max. av. Output: <1mW
IEC 60825 - 1, Ed, 2, 2007
CLASS 2 LASER PRODUCT
Complies with 21CFR 1040.10 and 1040.11
except for deviations pursuant to laser notice
No. 50. dated July 26. 2001
June 24. 2007
Mounting Assembly (beneath the top cover)
2 STINGER, A GUIDE TO ADHESIVE DOT DISPENSING
2.1 WARNING, MANDATORY AND SAFETY NOTICES
GUIDE TO ADHESIVE DOT DISPENSING STINGER 03/2021 9
Manufacturer: Techc n
Address: 12151 Monarch Street,
Garden Grove,
CA. 92841
Country of Manufacture: USA
Manufacture Date:
Month Year
Complies with 21CFR1040 with
deviations pursuant to Laser Notice 50.
SYSTEMS
Located on the rear face of the Stinger body
