TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
3.116 Appendix to Micron Technical Manuals Chapter Issue 1 June 15
Figure 3-13 Squeegee Mechanism
View on Front of Print Carriage
Spindle Shafts
Grease Nipples
Drive Belts
Leadscrew (rear squeegee
leadscrew not shown)
Supernut (rear squeegee
supernut not shown)
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
Chapter Issue 1 June 15 Appendix to Micron Technical Manuals 3.117
Figure 3-14 Rail System
Horizontal Linear Bearing
Guide (in 2 positions)
Ballscrew
(in 2 positions)
Clatter Bar
(in 2 positions)
Vertical Linear Bearing
Guide (in 4 positions)
Plan View on Rail Drive System
View on Left Side of Machine
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
3.118 Appendix to Micron Technical Manuals Chapter Issue 1 June 15
Figure 3-15 Underscreen Cleaner
View from Left Side of Machine
Camera Y Linear
Bearing Guide Rail
(in 2 positions)
USC Linear
Bearing Block
(in 2 positions)
USC Magnet
(in 2 positions)
USC Home Sensor
