Pos. Item no. Description Part marking
00301069-03 CABLE:TRAFO - POWER SUPPLY SPARE PART
00300379-05 CABLE: POWER F. COMPONENT
TABLE
6 00300380-07 CABLE:CONTROL SIGNALS,
COMPONENTS-TABLE
SPARE PART
00320594-04 CABLE WPW 80F/3 Y241-W1, INPUT SPARE PART
00320596-03 CABLE WPW 80F/3 Y242-W2,W3 SPARE PART
208 00300379-05 CABLE: POWER F. COMPONENT
TABLE
211 00328703-01 CABLE : COMP. TABLE - LED SMD SPARE PART
212 00328753-03 CABLE:CONTROL SIGNALS,
COMPONENTS-TABLE
SPARE PART
03048170-02 CABLE: EMERGENCY STOP INT.
03048171-02 CABLE: POWER FROM LINE FILTER
03048172-02 CABLE: TO TRANSFORMER
03049709-01 GROUND STRAND CONTROL UNIT
03048170-01 CABLE: EMERGENCY STOP
03048171-01 CABLE: POWER FROM LINE FILTER
03048172-01 CABLE: TO TRANSFORMER
03048173-01 CABLE: 26V~ L1-L3 / 24V DC
03048175-01 CABLE: UZK 200V DC
03047288-01 CABLE: CONTROL ON / INTERMED.
CIRCUIT ON
03048176-01 CABLE: UNBLOCKING BRAKE
03049187-01 GROUND WIRE (PE2)
03049181-01 GROUND WIRE (PE1)
03049183-01 GROUND WIRE (PE3)
03049184-01 GROUND WIRE (PE4)
03049185-01 GROUND WIRE (PE5)
03049186-01 GROUND WIRE (PE6)
03049188-01 GROUND WIRE (PE8)
03076760-01 CABLE: EMERGENCY STOP
INTERFACE
03048171-02 CABLE: POWER FROM LINE FILTER
03048172-02 CABLE: TO TRANSFORMER
03057251-01 CABLE: 24VDC / 30VAC L1-L3 /
35VDC
