CL5970
Tip Cleaning Rods
Packing List
003 4512-260724
INSTRUCTION MANUAL
Tip Cleaning Rods ..... 2 sets
Manual ......................... 1 unit
Ref. 0034512
CL5970 includes 2 tip cleaning
rod sets of different sizes. They
are used to clean or clear
clogged desoldering tips.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
Tip Maintenance
To avoid clogging or pressure loss on the desoldering tool, clean the tip periodically.
It may also be necesarry to clean the tip
from the other side.
Tip Cleaning
Rod
Clean with the cleaning
rod also from the top.
Clean the inside regularly with the largest
possible rod. Insert the rod pressing
lightly while rotating it.
This operation should be performed while the tip is hot (min. temperature
of 250 °C) so that the tin inside is molten and easier to remove.
Proceed with caution.
