P-196-001e - 第119页
MEMO
MODEL TCM-3100J-2
0108-001
116
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
5-4
82 411 141 3001 WASHER SPR 6 8 SW6
83 630 000 7909 BOLT,HEX-SCT 8 M6X25
86 630 066 0791 PLATE 1 659C--03B-162
87 411 141 4008 WASHER V 4X9X0.8 2 FW4
88 630 000 7664 BOLT,HEX-SCT 2 M4X20
90 630 056 1869 NAME PLATE,INDEX 6 659C--03H-024
91 411 141 6507 WASHER F 12X21X2.5 8 FWS12
92 411 141 3308 WASHER SPR 12 8 SW12
93 630 070 5287 BOLT,HEX-SCT 8 659C--03H-146
94 411 141 4503 WASHER V 8X17X1.6 4 FW8
95 411 141 3100 WASHER SPR 8 4 SW8
96 630 000 8036 BOLT,HEX-SCT 4 M8X30
MEMO
MODEL TCM-3100J-2
0108-001
118
ㇱຠଏ⛎ㇱ FEEDER CARRIAGE SECTION
Fig. 5-5 ࠹ࡊࠛࡦ࠼ᬌㇱ Tape End Detector
1
6
7
8
9
10
11
12
12
13
