The feeders must be regularly checked and then cleaned and/or serviced when necessary. This can significantly reduce
unscheduled feeder downtime. The
S-Feeder Test Station
can be used to check the following:
▪ General functionality
▪ The position of the teeth in the respective toothed wheel (pickup position).
▪ The play of the toothed wheel in the and across the direction of feeding.
If the check finds that tolerance values have been exceeded, we recommend that you pass the feeder concerned on to your
repair department. The
S-Feeder Test Station
is designed for use with the following
SIPLACE
feeders:
Designation Item No.
2 x 8 mm S II 00141096-xx
3 x 8 mm S 00141098-xx
3 x 8 mm SL 00141088- xx
3 x 8 mm S; 0201/0402 00141099- xx
12/16 mm S 00141092- xx
24 / 32 mm S 00141093- xx
44 mm S 00141094- xx
56 mm S 00141095- xx
72 mm S 00141097- xx
88 mm S 00141070- xx
Introduction – Use of Symbols
8
– Use of Symbols
Conventions for the Use of Hazard Symbols
This typeface Marks controls and interface elements in the software.
Marks tasks which are to be performed by the user
NOTICE
Notice
as used in this Operation Manual provides information on the product or indicates a part of the Operation Manual
that requires particular attention.
CAUTION
Attention
as used in this Operation Manual means that slight injury or damage to equipment may occur if the caution instruc-
tions are not followed.
WARNING
Warning
as used in this Operation Manual means that death, severe injury or considerable damage to equipment may occur
if the warning instructions are not followed.
