Performing the Test – Results Display: Name Protocol
37
Performing the Test – Results Display: Display Protocol
38
– Results Display: Display Protocol
After confirming the serial number, the whole test result will
be shown as a PDF file.
This log can be saved or printed out from this PDF.
Use the two arrow buttons in the center of the menu bar to
browse through the log.
If you click on the Save as PDF button in the PDF window,
the file will be saved.
If you click on the Close button in the PDF window, the re-
sults display will be shown.
Performing the Test – Results Display: Save Protocol
39
– Results Display: Save Protocol
If you click on the Save as PDF button in the PDF window,
the folder structure for the test computer will be shown in the
Explorer.
Select the storage path and change the name of the log file
if required.
The feeder serial number or the name you previously en-
tered is preset as the log file name.
