Performing the Test – Test with feeder feducial (for 2x8mm S Fe eder only) 50

Performing the Test – Test with feeder feducial (for 2x8mm S Feeder only)

NOTICE

Measuring without checking the feeder feducial

Feeder which has been tested this way should be marked respectively.

The checking of the feeder feducial can be deactivate for 2x8mm S-Feeder only.

The following warning will be shown on the display and in the protocol.

WARNING

Feducial recognition deactivated

Checking is performed without feducial recognition.

This function is available for 2x8mm S-Feeder only. In case the feducial cannot be identified by the position recog-

nition the feducial regognition can be deactivated. These feeder must not be used at the station using the feeder

recognition function.

Performing the Test – Test with feeder feducial (for 2x8mm S Feeder only)

Function Test – Introduction

Function Test– Introduction

Via menu "Extras" and "function test" more feeder checks

are available.

As for the other function you need to select the right feeder

type in the basic menu.

You can select the tracks (1) to be check for the foil retrac-

tion and stop position measurement.

Each test can be canceled using the "Cancel test" button.
