MODEL TCM-3700 9912-001 1 1-12 PART No. PART NAME Q'ty REMARK S 118 -1 630 066 20 54 STAY 1 739FB-01V-037 119 630 066 20 47 COV ER 1 739FB-01V -036 120 630 060 56 62 FILTER ,NOISE 1 739FB-01D-135 121 411 119 21 04 W…
MODEL TCM-3700
9912-001
11-12
PART No. PART NAME Q'ty REMARKS
32 630 000 7756 BOLT,HEX-SCT 8 M5X12
41 630 084 9776 PLATE 1 739FB-01V-030
42 630 065 8965 P.C.B,MOUNT(MEKAHAI) 1 739FB-01U-003
43 411 119 1909 WASHER V 3X7X0.5 4 FW3 F
44 411 086 4408 WASHER SPR 3 4 SW3 F
45 411 113 0700 SCR PAN 3X16 4 M3X16 PAN
46 630 051 6722 COVER 1 739FB-01V-032
47 630 051 6739 COVER 1 739FB-01V-034
48 411 141 4008 WASHER V 4X9X0.8 4 FW4
49 411 141 2905 WASHER SPR 4 4 SW4
50 630 000 7619 BOLT,HEX-SCT 4 M4X8
51 630 076 1788 COVER 1 739FB-01V-031
52 411 051 2804 SCR TRS 4X8 4 M4X8 TRS
53 411 141 4107 WASHER V 5X10X1 3 FW5
54 411 141 6705 WASHER SPR 5 3 SW5
55 630 000 7756 BOLT,HEX-SCT 3 M5X12
56 630 053 4689 TRANSFORMER,POWER 1 739FB-01D-011
57 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
58 411 141 3001 WASHER SPR 6 4 SW6
59 630 000 7879 BOLT,HEX-SCT 4 M6X12
68 411 113 9109 SCR TRS 5X10 26 M5X10 TRS
73 411 113 9109 SCR TRS 5X10 8 M5X10 TRS
87 630 060 7352 PANEL 1 739FB-01V-005
88 630 060 1718 CORD 1 739FB-01D-121
89 630 060 1718 CORD 1 739FB-01D-121
91 630 057 9307 CORD 1 739FB-01D-123
92 630 066 8513 CONNECTOR 2 739FB-01D-112
93 630 056 9537 CORD 2 739FB-01D-113
95 630 001 0220 WASHER 2 BW5
96 411 141 6705 WASHER SPR 5 2 SW5
97 630 000 7749 BOLT,HEX-SCT 2 M5X10
100 630 061 6392 COVER 1 739FB-01V-024
101 630 061 6408 COVER 1 739FB-01V-025
102 630 058 2574 FILTER,NOISE 2 739FB-01D-136
103 411 119 2104 WASHER V 4X9X0.8 8 FW4 F
104 411 008 1706 WASHER SPR 4 8 SW4 F
105 411 043 5004 SCR PAN 4X8 8 M4X8 PAN
106 630 001 0220 WASHER 2 BW5
107 411 141 6705 WASHER SPR 5 2 SW5
108 630 000 7756 BOLT,HEX-SCT 2 M5X12
108 -1 411 036 8609 SCR PAN+SW+W 5X12 2
111 630 060 5662 FILTER,NOISE 3 739FB-01D-135
112 411 119 2104 WASHER V 4X9X0.8 6 FW4 F
113 411 008 1706 WASHER SPR 4 6 SW4 F
114 411 043 5004 SCR PAN 4X8 6 M4X8 PAN
115 630 060 7420 ROD 12 739FB-01V-026
116 630 061 3902 COVER 3 739FB-01V-027
117 411 051 1708 SCR TRS 4X6 9 M4X6 TRS
117 -1 411 114 7807 SCR PAN+SW+W 4X10 3
118 630 066 2061 STAY 1 739FB-01V-038
Key No.
NOTE
MODEL TCM-3700
9912-001
11-12
PART No. PART NAME Q'ty REMARKS
118 -1 630 066 2054 STAY 1 739FB-01V-037
119 630 066 2047 COVER 1 739FB-01V-036
120 630 060 5662 FILTER,NOISE 1 739FB-01D-135
121 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
122 411 008 1706 WASHER SPR 4 2 SW4 F
123 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
124 411 051 1708 SCR TRS 4X6 2 M4X6 TRS
124 -1 411 114 7807 SCR PAN+SW+W 4X10 1
Key No.
NOTE
MODEL TCM-3700
9912-001
電気制御部 ELECTRICAL SECTION
Fig.11-13 機械廻り 2(ベース上面部) Miscellaneous Parts-2
