MODEL TCM-3700 9912-001 ヘッド駆動部 HEAD DRIVING SECTION Fig. 3-16 テープ送り部 1 T ape Feed-1
MODEL TCM-3700
9912-001
3-15
PART No. PART NAME Q'ty REMARKS
1 630 048 9736 SUPPORT 2 739K--01B-062
2 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
3 411 141 3001 WASHER SPR 6 4 SW6
4 630 000 7923 BOLT,HEX-SCT 4 M6X35
5 630 052 1559 PLATE 1 739K--01B-063
6 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
7 411 141 3001 WASHER SPR 6 4 SW6
8 630 000 7909 BOLT,HEX-SCT 4 M6X25
10 630 060 4856 ASSY,LEVER(STOPPER TYPE3) 4
11 630 051 6494 BASE 1 739K--01B-093
12 630 055 2881 SHAFT 1 739K--01B-030
13 630 048 7251 LEVER 1 739K--01B-032
14 630 000 8944 SET SCREW 1 M5X6 SET
15 630 001 1272 BEARING,RADIAL 2 739K--01H-012
16 411 051 1708 SCR TRS 4X6 4 M4X6 TRS
17 630 060 4931 ASSY,CYLINDER(STOPPER R) 4
17 -1 630 055 2874 CYLINDER 1 739K--01H-053
17 -2 630 000 0436 CASE,CONN 1
17 -3 630 000 4281 CABLE JOINT,TERMINAL 2
18 411 118 8503 NUT HEX 5 4 M5 F
19 630 000 8630 BOLT,HEX 4 M5X20 HEX
20 630 029 1391 WASHER 16 739K--01H-048
21 411 141 6705 WASHER SPR 5 16 SW5
22 630 000 7770 BOLT,HEX-SCT 16 M5X20
51 630 051 3813 PIPE FITTINGS 1 739K--01H-054
52 630 003 7814 PIPE FITTINGS 1
53 630 003 7791 PIPE FITTINGS 2
54 411 141 3902 WASHER V 3X7X0.5 2 FW3
55 411 141 2806 WASHER SPR 3 2 SW3
56 630 000 7572 BOLT,HEX-SCT 2 M3X25
Key No.
NOTE
MODEL TCM-3700
9912-001
ヘッド駆動部 HEAD DRIVING SECTION
Fig. 3-16 テープ送り部 1 Tape Feed-1
MODEL TCM-3700
9912-001
3-16
PART No. PART NAME Q'ty REMARKS
630 060 6720 ASSY,BRACKET,LOCATE(PF) 1
10 630 056 9230 BRACKET,LOCATE 1 739KB-01B-126
11 630 081 8154 GUIDE,LINEAR 1 739KB-01H-101
11 -1 630 048 3215 COLLAR 1 739KB-01B-122
11 -2 630 048 3222 COLLAR 1 739KB-01B-123
11 -3 630 049 3047 SPRING,COMP 1 739KB-01B-134
12 411 140 8007 SCR TRS 5X6 1 M5X6 TRS
13 630 087 4242 SET SCREW 1 739KB-01H-113
14 411 141 0307 NUT HEX 4 1 M4
15 630 049 0015 COLLAR 1 739KB-01B-133
16 630 000 8883 SET SCREW 2 M3X4 SET
17 630 048 3192 SHAFT 1 739KB-01B-120
18 411 141 4305 WASHER V 6X12.5X1.6 1 FW6
19 411 141 3001 WASHER SPR 6 1 SW6
20 411 141 0703 NUT HEX 6 1 M6
21 630 081 8147 GUIDE,LINEAR 4 739KB-01H-102
21 -1 630 048 3208 COLLAR 4 739KB-01B-121
21 -2 630 048 3222 COLLAR 4 739KB-01B-123
21 -3 630 049 3054 SPRING,COMP 4 739KB-01B-135
22 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
23 630 087 4242 SET SCREW 4 739KB-01H-113
24 411 141 0307 NUT HEX 4 4 M4
25 -1 630 056 9513 BLOCK 1 739KB-01B-115
25 -2 630 056 9506 BLOCK 1 739KB-01B-114
25 -3 630 056 9520 BLOCK 1 739KB-01B-116
25 -4 630 056 9490 BLOCK 1 739KB-01B-113
26 630 007 2457 CAM FOLLOWER 4 739KB-01H-108
27 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
28 411 141 3001 WASHER SPR 6 4 SW6
29 411 141 0703 NUT HEX 6 4 M6
30 411 000 7102 RING C 10 4 739KB-01H-107
31 411 141 4107 WASHER V 5X10X1 4 FW5
32 411 141 6705 WASHER SPR 5 4 SW5
33 630 000 7763 BOLT,HEX-SCT 4 M5X16
41 630 059 5604 GUIDE,LINEAR 2 739KB-01H-103
41 -1 630 048 3208 COLLAR 2 739KB-01B-121
41 -2 630 059 5635 COLLAR 2 739KB-01B-142
41 -3 630 059 5628 SPRING,COMP 2 739KB-01B-136
42 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
43 630 057 9741 PLATE,LOCATE 1 739KB-01B-117
44 630 001 0237 WASHER 2 739KB-01H-110
45 411 141 3001 WASHER SPR 6 2 SW6
46 630 000 7886 BOLT,HEX-SCT 2 M6X16
47 630 048 3239 PIN,GUIDE 1 739KB-01B-124
48 411 141 4107 WASHER V 5X10X1 1 FW5
49 411 141 6705 WASHER SPR 5 1 SW5
50 411 141 0505 NUT HEX 5 1 M5
51 630 048 7503 GUIDE,LINEAR 1 739KB-01H-104
51 -1 630 048 3208 COLLAR 1 739KB-01B-121
52 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
Key No.
NOTE
