P-138-001e - 第67页
MEMO
MODEL TCM-3700
9912-001
3-16
PART No. PART NAME Q'ty REMARKS
53 630 087 4242 SET SCREW 1 739KB-01H-113
54 411 141 0307 NUT HEX 4 1 M4
55 630 049 3078 SPRING,COMP 1 739KB-01B-137
56 630 059 5611 BLOCK 1 739KB-01B-112
57 411 141 4107 WASHER V 5X10X1 2 FW5
58 411 141 6705 WASHER SPR 5 2 SW5
59 630 000 7763 BOLT,HEX-SCT 2 M5X16
Key No.
NOTE
MEMO
MODEL TCM-3700
9912-001
ヘッド駆動部 HEAD DRIVING SECTION
Fig. 3-17 テープ送り部 2 Tape Feed-2
