MEMO

MODEL TCM-3700

9912-001

4- 4

PART No. PART NAME Q'ty REMARKS

51 411 141 4503 WASHER V 8X17X1.6 1 FW8

52 411 141 3100 WASHER SPR 8 1 SW8

53 411 141 0901 NUT HEX 8 1 M8

56 630 002 3770 SPRING,COMP 1 739EB-01H-025

57 630 001 0244 WASHER 2 739EB-01H-035

58 411 141 3100 WASHER SPR 8 2 SW8

59 630 000 8036 BOLT,HEX-SCT 2 M8X30

60 630 042 2139 WASHER 1 739EB-01H-028

61 630 050 0721 ROD 1 739EB-01B-022

62 411 141 0703 NUT HEX 6 1 M6

63 630 001 1050 ROD END 1 739EB-01H-026

63 630 052 7179 ROD END 1

64 630 050 1032 ROD END 1 739EB-01H-037

64 630 052 7124 ROD END 1

65 630 050 0738 ROD 1 739EB-01B-029

66 411 141 0703 NUT HEX 6 1 M6

67 630 000 9743 NUT,HEX 1 M6-L

68 630 033 5248 BOLT,HEX 1 739EB-01H-027

69 411 141 3001 WASHER SPR 6 1 SW6

70 411 141 0703 NUT HEX 6 1 M6

71 630 008 2395 BOLT,HEX 1 739K--01H-028

72 411 141 4305 WASHER V 6X12.5X1.6 1 FW6

73 411 141 3001 WASHER SPR 6 1 SW6

74 411 141 0703 NUT HEX 6 1 M6

Key No.

NOTE

MEMO

MODEL TCM-3700

9912-001

中間ベース部 MIDDLE BASE SECTION

Fig. 4-5 部品姿勢検出、ノズル検出 Component Posture Detector,Nozzle Detector
