Introduction Abbreviations 1.3.5 SIPLACE on the World Wide Web (WWW) 12 Operating Manual SIPLACE WPC5/WPC6
Introduction
1.3.5 SIPLACE on the World Wide Web (WWW) Abbreviations
Operating Manual SIPLACE WPC5/WPC6 11
1.4
1.4 Abbreviations
Abbreviations
CO Component
COT Changeover table
COT-i Changeover table insert
C&P Collect&Place
C&P12 Collect&Place head with 12 segments
C&P20 Collect&Place head with 20 segments
C&P6 Collect&Place head with 6 segments
CPP Collect&Pick&Place head
EMC Electromagnetic compatibility
ESD Electrostatic sensitive device
PA Placement area
PCB Board
P&P Pick&Place
SC Station computer
TH TwinHead
VS Vision system
WPC Wafflepack Changer
WPC4 Wafflepack Changer Version 4
WPC 5 Waffle Pack Changer Version 5
WPC6 Waffle Pack Changer Version 6
Introduction
Abbreviations 1.3.5 SIPLACE on the World Wide Web (WWW)
12 Operating Manual SIPLACE WPC5/WPC6
Operational Safety
2.1.1 Conventions for the Use of Safety Instructions Safety Instructions
Operating Manual SIPLACE WPC5/WPC6 13
2
2 Operational Safety
Operational Safety
2.1
2.1 Safety Instructions
Safety Instructions
2.1.1
2.1.1 Conventions for the Use of Safety Instructions
Conventions for the Use of Safety Instructions
Always follow the safety instructions in this manual to ensure your personal safety and to avoid damage
to property. These instructions are marked by triangular warning symbols and show the degree of hazard
as follows:
2.1.2
2.1.2 Important Notes on Operational Safety
Important Notes on Operational Safety
DANGER
Nonobservance increases the risk of injury and/or damage to the machine!
► Please observe the safety instructions in the relevant user manual of the machine for all
service work!
DANGER
For the purposes of this manual, this indicates that fatal or severe injuries or considerable dam-
age to property will occur if these warning instructions are not observed.
WARNING
For the purposes of this manual, this indicates that fatal or severe injury or considerable dam-
age to property may occur if this warning is not observed.
CAUTION
For the purposes of this manual, this indicates that minor injury or damage to property may oc-
cur if this caution is not observed.
NOTICE
For the purposes of this manual, this note provides information about the product or indicates
a part of the manual that requires particular attention.
WARNING
The following points MUST be observed in order to maintain operational safety:
