Module Technical Data Connection Values 3.3.1 Electrical Connections 26 Operating Manual SIPLACE WPC5/WPC6 3.3 3 . 3 C o n n e c t io n V a lu e s Connection Values 3.3.1 3 . 3 . 1 E le c t r ic a l C o n n e c t io n s …
Module Technical Data
Overview of WPC5/WPC6
Operating Manual SIPLACE WPC5/WPC6 25
3
3 Module Technical Data
Module Technical Data
The Technical data of WPC5 and WPC6 are basically identical. Any differences are explicitly pointed out.
3.1
3.1 Overview of WPC5/WPC6
Overview of WPC5/WPC6
3.2
3.2 Overview of the Modules
Overview of the Modules
1. SIPLACE SX1/SX2
2. WPC6
3. Non-Stop Module (only WPC6)
4. Changeover table with 30 tracks
1. Protective door
2. Non-Stop Module (only WPC6)
3. EMERGENCY STOP button
4. Main switch
5. Protective covers on the power supply
6. Crank handle for lifting or lowering the trolley carriage
7. Protective covers on the lifting mechanism (tower)
8. Feed axis with waffle pack tray carrier
9. Cover over the feed axis drive
Module Technical Data
Connection Values 3.3.1 Electrical Connections
26 Operating Manual SIPLACE WPC5/WPC6
3.3
3.3 Connection Values
Connection Values
3.3.1
3.3.1 Electrical Connections
Electrical Connections
3.3.2
3.3.2 Environmental Conditions for Operation
Environmental Conditions for Operation
3.3.3
3.3.3 Pneumatic Connections and Compressed Air Specifications
Pneumatic Connections and Compressed Air Specifications
Supply voltage 3 x 208 V~ ± 10 %; 50/60 Hz (U.S.A)
3 x 230 V~ ± 10 %; 50/60 Hz
3 x 380 V~ ± 10 %; 50/60 Hz
3 x 400 V~ ± 10 %; 50/60 Hz (Europe)
3 x 415 V~ ± 10 %; 50/60 Hz
Nominal apparent power 1.5 kVA
Nominal active power 1.0 kW
Fuse rating 3 x 10 or 3 x 16 A
Room temperature between 15°C and 35°C
Humidity 30% to 75%(but no higher than 45% on average in
order to prevent any possibility of condensation on
the machine).
Air connection, vacuum connection Not applicable
Module Technical Data
3.3.4 Dimensions and Weight Connection Values
Operating Manual SIPLACE WPC5/WPC6 27
3.3.4
3.3.4 Dimensions and Weight
Dimensions and Weight
WPTC = waffle pack tray carrier
Dimensions (L x W) 1520 mm x 360 mm
Height
at 900 mm ± 15 mm PCB conveyor height
at 930 mm PCB conveyor height
at 950 mm PCB conveyor height
1430 mm
1460 mm
1480 mm
WPC5 Weight
Basic equipment (with cassettes and waffle pack tray carriers)
Fully equipped (with waffle pack tray carriers and cassettes in-
cluding components)
approx. 270 kg
approx. 280 kg
WPC6 Weight
Basic equipment (with cassettes and waffle pack tray carriers)
Fully equipped (with waffle pack tray carriers and cassettes in-
cluding components)
approx. 320 kg
approx. 330 kg
Load per unit area ≤ 25 N/cm²
Dimensions of the WTC (L x W x H) 360 mm x 260 mm x 6 mm
Dimensions of the waffle pack tray (L x W x H)
Including components
For high components if the WTC for the next level is not used
High component mode
347 mm x 235 mm x 15 mm
347 mm x 235 mm x 29 mm
347 mm x 235 mm x 32 mm
Weight of waffle pack tray carrier
Empty
Including waffle pack tray and components
0.8 kg
max. 1.2 kg
Storage capacity max. 28 WPTCs
Total weight of 28 WPTCs 27.6 kg
Total permissible load (magazine storage units, WPTCs, WPTs
and components)
max. 50 kg
Changeover time for WPTC
for 1 level
for 10 levels
for 27 levels
1.9 s
2.3 s
2.9 s
Free feeder locations (SX1/SX2) 30
