SIPLACE Smart Pin Support (SPS)
Die new option SPS is available for SX1/SX2 and will be available also for the
X Series S.
SPS helps the operator during download a new job to the machine to set the PCB
support pins automatically by the machine itself.
Preconditions:
- Station Software 706.0x / Siplace Pro10.x
- New head holder for SX1/2 New Gantry Version-04
- New Headinterface
- Conveyor V2
General description:
The pin position will be described in Siplace Pro like a placement list. Together with the
setup, the data will be send to the machine. The machine recognizes the available pins
and sets the pins onto the programmed position.
