Overview Configuration SPS
Calibration and Test Smart Pin Support
Configuration
Parts
General
Project Organization
20.04.2017 Page 3
General
SIPLACE Smart Pin Support (SPS)
Die new option SPS is available for SX1/SX2 and will be available also for the
X Series S.
SPS helps the operator during download a new job to the machine to set the PCB
support pins automatically by the machine itself.
Preconditions:
- Station Software 706.0x / Siplace Pro10.x
- New head holder for SX1/2 New Gantry Version-04
- New Headinterface
- Conveyor V2
General description:
The pin position will be described in Siplace Pro like a placement list. Together with the
setup, the data will be send to the machine. The machine recognizes the available pins
and sets the pins onto the programmed position.
20.04.2017 Page 4
PinPicker SX1/2
One SPS Pin Picker is necessary to support the
specified length of PCB boards in the SX1/2 machine.
The Pin Picker will be mounted on gantry 1 only.
Sales-Article No.:00119992 SPS PinPicker SX1/2:
containing: 03089621-xx Pin Picker SX1/2 (Gantry 1 left)
Variant für SX1/2 with 40mm gantry (different base plate):
Sales-Article No.: 00519988-xx SPS Pin Picker Twin VHF 40mm
containing: 03104671-xx SPS pin picker 40mm machine
Smart Pin Support (SPS) - Pin Picker
1. Pneumatic valves
2. Pneumatic cylinder
3. Control board
4. Assembly holes
5. Pneumatic tube and electrical cable
6. Linear guide
7. Pin interface
8. Base plate
