General
SIPLACE Smart Pin Support (SPS)
Die new option SPS is available for SX1/SX2 and will be available also for the
X Series S.
SPS helps the operator during download a new job to the machine to set the PCB
support pins automatically by the machine itself.
Preconditions:
- Station Software 706.0x / Siplace Pro10.x
- New head holder for SX1/2 New Gantry Version-04
- New Headinterface
- Conveyor V2
General description:
The pin position will be described in Siplace Pro like a placement list. Together with the
setup, the data will be send to the machine. The machine recognizes the available pins
and sets the pins onto the programmed position.
20.04.2017 Page 4
PinPicker SX1/2
One SPS Pin Picker is necessary to support the
specified length of PCB boards in the SX1/2 machine.
The Pin Picker will be mounted on gantry 1 only.
Sales-Article No.:00119992 SPS PinPicker SX1/2:
containing: 03089621-xx Pin Picker SX1/2 (Gantry 1 left)
Variant für SX1/2 with 40mm gantry (different base plate):
Sales-Article No.: 00519988-xx SPS Pin Picker Twin VHF 40mm
containing: 03104671-xx SPS pin picker 40mm machine
Smart Pin Support (SPS) - Pin Picker
1. Pneumatic valves
2. Pneumatic cylinder
3. Control board
4. Assembly holes
5. Pneumatic tube and electrical cable
6. Linear guide
7. Pin interface
8. Base plate
20.04.2017 Page 5
Smart Pin Support (SPS) - Pin
Support Pin
Sales-Article No.:119995 for 5 pieces Pins
