Smart Pin Support (SPS) - Pin
Support Pin
Sales-Article No.:119995 for 5 pieces Pins
20.04.2017 Page 6
Smart Pin Support (SPS) – Magazine Q10
SPS magazine Q10
SPS Magazine Q10 – 03087508-xx for SX1/2
Magazine holder Q10cpl. – 03088072-xx
1. Calibration garage
2. Position fiducial
1
2
Sales-Article No.:119997 Magazine Q10
20.04.2017 Page 7
Smart Pin Support (SPS) – Magazine L10
SPS magazine L10
(lengthwise)
SPS Magazine L10 – 03087404-xx for SX1/2
Magazine holder L10cpl. – 03087886-xx
1
2
1. Calibration garage
2. Position fiducial
Sales-Article No.:119996 Magazine L10
