46 Technical Data Placement System Dimensions
45
Technical Data
Dimensions and Setup Conditions
Length 1900 mm
Width 2735 mm
Height of machine (for PCB conveyor height 930 mm)
up to upper edge of monitor
with indicator lamp
with folded-up protective covers
1630 mm
2110 mm
2120 mm
Machine ground clearance
(for PCB conveyor height 900 mm)
(for PCB conveyor height 930 mm)
(for PCB conveyor height 950 mm)
120 mm ± 15 mm
150 mm ± 15 mm
170 mm ± 15 mm
Weight
DX4 with 4x DX tables (empty)
DX4 with 4x DX tables (fully configured)
3460 kg
3938 kg
Location
DX4 with 4x DX tables 6.87 m²
Load per unit area
DX4 with 4x DX tables 6.34 kN/m²
Number of machine feet 6
Maximum noise emissions 75 dB (A)
Room temperature between 15°C and 35°C
Atmospheric humidity 30% to 75 % (no higher than 45% on average to
prevent any possibility of condensation on the
machine)
46
Technical Data
Placement System Dimensions
47
Technical Data
Placement System Center of Gravity
X = 0 mm
Y = 0 mm
Z = 630 mm
