C&P6/12 Placement Head
Training Note Overview
Student Guide Advanced Level 2 SIPLACE D Series
EN 05/2007 C&P6/12 Placement Head
8-3
8.1.4 Training Note
You know the C&P placement head from your work or from the AL1 course, so that explanations and
illustrations would only be a repetition here.
In this advanced course, we will be covering in detail the programming options and their influence on the
placement head procedure.
If any questions arise or you do not understand anything, please clarify this at once. You will not benefit
from waiting until the end of the course.
8-2: C&P12 head
Legend - overview of parts 2
1. Forced air unit with electromagnetic valve
(version 02 – downwards compatibility)
[00367793-xx]
2. Silencer
[03003134-xx]
3. Turning station / DLM2
[00341780-xx]
4. Component camera 18x18
[03014449-xx]
Component camera 27 x 27
[03018637-xx]
5. Compressed air supply for forced air unit
6. Compressed air supply for vacuum generator
(holding circuit and pick/place)
7. Vacuum measurement board (under the
cover)
8-3: C&P12 head
Legend - overview of parts 3
1. Star fitted / DLM2
2. "Z-axis down" sensor
3. RSF digital encoder 12/DLM2
4. Circular guide (raceway), aligned to star drive
axis
5. Star drive axis, centered by head housing and
Z-axis claw
C&P6/12 Placement Head
Reference Run (D-Series) Overview
Student Guide Advanced Level 2 SIPLACE D Series
C&P6/12 Placement Head EN 05/2007
8-4
8.2 Reference Run (D-Series)
The placement machine reference run guaranties the correct function for placement in the station SW.
This is where the reference runs for the C&P head and for the gantry are described. A separate chapter
describes the reference run for the P&P module, performed parallel to that for the C&P head.
8.2.1 Overview
The reference run is divided into 4 main steps. Module reference runs for the WPC or for a 2nd
placement head per gantry are not listed at this stage.
1. Conveyor system reference run
This activates the unoccupied (not occupied with a PCB) conveyors.
(in older SW versions, this function can also be performed to conclude the reference run.)
2. Axis reference run
This is divided into:
A.) the head axis reference run and
B.) the gantry axis reference run.
The gantry head axes are started at the same time. As many functions as possible are performed at
the same time.
3. Vacuum reference run
The
A.) vacuum values "open" and "closed" for placement are determined and
B.) all segments in the DP stations are rotated into their 0 degrees positions.
4. Height Reference Run
This function tests the length of the segment nozzles and of the heads in a placement area, on the
top surface of a conveyor side.
These are described and explained in detail below. Machine type or configuration-related extensions or
deviations are explained in separate texts to prevent confusion.
8.2.2 Reference Run Details
NOTE: Reference run details
The reference run details can be found in the AL1 course documents in the chapter Reference
Run.
C&P6/12 Placement Head
Z-Axis Down Travel Profile - Pickup
Student Guide Advanced Level 2 SIPLACE D Series
EN 05/2007 C&P6/12 Placement Head
8-5
8.3 Travel Profile - Pickup
8.3.1 Z-Axis Down
8.3.1.1 Detailed Standard Pickup Procedure: Z-Axis Down
8-4: Star position 0°: detailed pickup procedure: Z-axis down
Start gantry axes to pickup position of next feeder
and communication with changeover table: Start
signal to gantry axes
Start signal X & Y axis to next feeder/this
opens the feeder flap
End position signal for X/Y and star axes:
End position signal for star axis
Enables vacuum query: "segment airtight?"
before pickup
X/Y end position signals available.
Z-axis starts:
Z-axis starts positioning downwards
Light barrier (LB) up switches:
Release signal for function LB down, (after a
waiting period of approx. 3.6 ms, depending
on the DIP switch, special function, currently
not active as a default)
LB down switches:
End position signal for positioning Z-axis down
and valve positioning drive ON for vacuum.
Legend
1. End position signal for Y-axis (position to
feeder pickup position)
2. End position signal for star axis
3. Uncommutated motor current for Z-axis
4. End position signal for Z-axis
Section 1: move down
Section 2: move up
8 ms after the end position signal for the Z-
axis, the system switches over to vacuum and
the Z-axis is restarted and moved upwards.
