3.4.4 Pneumatic Unit
The pneumatic unit is a fixed installation inside the machine and is located to the right of the middle
section of the machine, behind a flap. The pneumatic unit includes all electrical connections for control/
regulation of the compressed air supply.
See also:
J 5.3 Pneumatic System [J5-12]
3.4.5 Power Supply Unit
The main power supply unit is mounted on a compact rack module and is located on the left side of the
middle section. When viewed from the outside, only the red main power switch is visible.
A lockable door prevents access to the power supply.
See also:
J 5.2 Power Supply Unit [J5-2]
3.4.6 SIPLACE Vision
For a diagram of the camera, details and technical background, refer to the chapter "Communication and
Control".
See also:
J 4.4 SIPLACE Vision [J4-19]
3.4.7 Waffle Pack Changer (WPC)
NOTE: Further information
For further information about the WPC, refer to the relevant student guide or service manual.
