MODEL GXH-1
1012-005
113
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
J-1
4Unit/1Machine
1 6301377605 BASE 1 803J--210-001 210A2394
2 6301377629 BASE 1 803J--210-002 210A2395
3
6301292618 SHAFT 2 803J--210-003 213A1093
5
6301254067 BRACKET 4 803J--210-005 211F8162
6 6301254074 HOLDER 2 803J--210-006 216B1388
7
6301254081 HOLDER 2 803J--210-007 216B1389
1
1 6301242859 SENSOR,PELEC 1 -B0510 Amp 803J--210-101
23G00244
12 6300746143 SENSOR,PELEC 2 -B0510 803J--210-102 23G00157
13 6301303796 BLOCK 1 803J--210-013 211G3705
14 6301303802 BLOCK 1 803J--210-014 211G3706
15 6301250144 SHAFT 1 803J--210-015 213A1030
16
6301267180 BRACKET 1 803J--210-016 211F8341
17 6301254111 BRACKET 1 803J--210-017 211F8164
18 6301290164 COVER 1 803J--210-018 211A8860
19 6301290171 COVER 1 803J--210-019 211A8861
20 6301288840 BRACKET 1 803J--210-020 211F8610
21 6301288857 BRACKET 1 803J--210-021 211F861
1
23 6300725766 SENSOR,PELEC 2 803J--210-103 23G00152
24
6301056456 SENSOR,PELEC 1 803J--210-104 23G00207
25
6301259468 GUIDE,LINEAR 2 803J--210-105 222L0694
28
6301242798 PIPE FITTINGS 6 803J--210-108 225F0558
30
6301255095 VALVE 1 -Y0932,-Y0933
803J--210-110 225C0108
31 6300467680 AIR LINE EQPT 2 803J--210-111
225B0245
32 6301255118 PIPE FITTINGS 1 803J--210-112 225F0567
33 6301090795 PIPE FITTINGS 2 803J--210-113 225F0452
34 6301242842 AIR LINE EQPT 4 803J--210-114 225B0497
35 6301243924 GEAR 2 803J--210-115 223E0369
37 6300010367 SPRING PIN 2 803J--210-117 221J0010
38 6300068795 BEARING,RADIAL 2 803J--210-118 222D0088
39 6301242767 SENSOR,PROXIMITY 2 -B0910,-B0911
803J--210-119 23G20066
42 6301255101 MECH PARTS(HOLDER) 8 803J--210-122 226J1887
51
6300007510 BOLT,HEX-SCT 2 M3X8 221A0006
52
6300007527 BOLT,HEX-SCT 2 M3X10 221A0007
53
6300007527 BOLT,HEX-SCT 4 M3X10 221A0007
54
6300007565 BOLT,HEX-SCT 2 M3X20 221A0011
55 6300007633 BOLT,HEX-SCT 2 M4X12 221A0018
56
6300007657 BOLT,HEX-SCT 16 M4X16 221A0020
57
6300007749 BOLT,HEX-SCT 6 M5X10 221A0029
58
6300007756 BOLT,HEX-SCT 8 M5X12 221A0030
59
6300008029 BOLT,HEX-SCT 4 M8X25 221A0057
60
6300008142 BOLT,HEX-SCT 2 M10X35 221A0069
61
6300008159 BOLT,HEX-SCT 2 M10X40 221A0070
62
4110418908 SCR PAN 3X6 2 M3X6 PAN 221E0497
63 4110420703 SCR PAN 3X8 4 M3X8 PAN 221E0499
64 4111132308 SCR PAN 4X25 8 M4X25 PAN 221E0505
66 4110512804 SCR TRS 4X8 4 M4X8 TRS 221E0533
68 4111410901 NUT HEX 8 2 M8 221F0089
71
4111412806 WASHER SPR 3 6 SW3 221H0281
MODEL GXH-1
1012-005
114
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
J-1
4Unit/1Machine
72 4111412905 WASHER SPR 4 2 SW4 221H0284
73 4111416705 WASHER SPR 5 14 SW5 221H0287
74
4111413100 WASHER SPR 8 6 SW8 221H0291
75
4111413209 WASHER SPR 10 4 SW10 221H0293
76
4111413902 WASHER V 3X7X0.5 6 FW3 221H0312
77
4111414008 WASHER V 4X9X0.8 2 FW4 221H0315
78
4111414107 WASHER V 5X10X1 14 FW5 221H0318
79
4111414503 WASHER V 8X17X1.6 4 FW8 221H0323
80
4111414701 WASHER V 10X21X2 4 FW10 221H0325
