MODEL GXH-1 1012-005 127 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE Q-1 4Unit/1Machine 1 6301350486 BASE 1 803Q--210-001 210A2338 2 6301397535 FRAME 1 803Q--210-002 210B3929 3 6301420356 BLOCK 5 829Q--010-…
MODEL GXH-1
0503-003
126
フィーダベース部
FEEDER BASE SECTION
Fig. Q-1
フィーダベース
Feeder Base
69
34
23
58
73
5
3
8
1
63
.
74
.
79
65
.
74
.
79
64
.
74
.
79
28
27
55
.
72
.
77
55
.
72
.
77
43
43
43
43
12
12
10
13
13
13
13
12
12
12
11
11
11
11
43
60
.
73
.
78
43
59
.
73
.
78
11
A
37
73
20
58
40
16
6
2
36
22
21
52
66
54
38
17
16
16
18
15
25
40
40
14
14
14
40
25
26
59
.
73
.
78
67
.
73
.
78
51
.
71
.
76
61
.
73
.
78
61
.
73
.
78
57
35
41
41
7
53
.
72
.
77
55
.
72
.
77
53
.
72
.
77
53
.
72
.
77
53
.
72
.
77
29
30
30
A
19
33
68
62
73
58
4
MODEL GXH-1
1012-005
127
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
Q-1
4Unit/1Machine
1 6301350486 BASE 1 803Q--210-001 210A2338
2 6301397535 FRAME 1 803Q--210-002 210B3929
3
6301420356 BLOCK 5 829Q--010-003 211G4404
4 6301376561 BLOCK 2 803Q--210-004 211G4122
5 6301376578 BLOCK 2 803Q--210-005 211G4123
6 6301376585 BLOCK 3 803Q--210-006 211G4124
7 6301404479 COVER 2 803Q--210-007 211AA184
8 6301376592 PLATE 26 803Q--210-008 211DA642
10 6301246222 SHAFT 5 803Q--210-010 213A1024
1
1 6301266756 PLATE 25 803Q--210-011 21
1D9584
12 6301246239 SPACER 50 803Q--210-012 211E0863
13 6301246253 SPRING,COMP 25 803Q--210-013 222M1298
14
6301267982 BLOCK 4 803Q--210-014 211G3512
15 6301376608 SHAFT 1 803Q--210-015 213A1216
16
6301253428 SPRING,FLAT 3 803Q--210-016 222Q0121
17
6301253435 SPRING,FLAT 1 803Q--210-017 222Q0122
18
6301253442 SPRING,FLAT 1 803Q--210-018 222Q0123
19
6301253541 ROD 1 803Q--210-019 216C0713
20
6301253558 LEVER 1 803Q--210-020 216S2611
21 6301249766 BLOCK 1 803Q--210-021 211G3390
22 6300022391 SPRING,COMP 1 803Q--210-022 222M0641
23
6301376615 BLOCK 3 803Q--210-023 211G4125
25 6301266930 SPACER 2 803Q--210-025 211E0871
26 6301268620 COVER 1 803Q--210-026 211A8645
27 6301298528 COVER 1 803Q--210-027 211A8958
28 6301298535 COVER 1 803Q--210-028 211A8959
29 6301292588 COVER 1 803Q--210-029 211A8876
30 6301376622 PIN,GUIDE 2 803Q--210-030 216F0935
33
6301254210 CYLINDER 1 -B6950,-B6951
803Q--210-103 224C0532
34
6301254197 AIR LINE EQPT 2 803Q--210-104 225B0506
35
6301249995 VALVE 1 -Y6930 803Q--210-105 225C0106
36 6300037265 PIPE FITTINGS 1 803Q--210-106 225F0023
37
6300036534 AIR LINE EQPT 2 803Q--210-107 225B0059
38
6301250045 CAM FOLLOWER 1 803Q--210-108 222H0132
40
6301240404 BUSH,BEARING 4 803Q--210-110 222A0148
41 6300095586 HINGE 2 803Q--210-111
226F0043
42 6301260068 NAME PLATE,INDEX 1 803Q--210-112 6P460124
43 4110007508 RING C 15 50 803Q--210-113 221K0079
51 6300007527 BOLT,HEX-SCT 2 M3X10 221A0007
52
6300007534 BOLT,HEX-SCT 1 M3X12 221A0008
53
6300007619 BOLT,HEX-SCT 10 M4X8 221A0016
54
6300007633 BOLT,HEX-SCT 1 M4X12 221A0018
55
6300007633 BOLT,HEX-SCT 8 M4X12 221A0018
57
6300007749 BOLT,HEX-SCT 19 M5X10 221A0029
58
6300007756 BOLT,HEX-SCT 8 M5X12 221A0030
59
6300007756 BOLT,HEX-SCT 12 M5X12 221A0030
60
6300007770 BOLT,HEX-SCT 10 M5X20 221A0032
61
6300007794 BOLT,HEX-SCT 8 M5X30 221A0034
62
6300007831 BOLT,HEX-SCT 4 M5X50 221A0038
MODEL GXH-1
1012-005
128
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
Q-1
4Unit/1Machine
63 6300858310 BOLT,HEX-SCT 6 M6X14 221A0240
64 6300007886 BOLT,HEX-SCT 4 M6X16 221A0043
65
6300007923 BOLT,HEX-SCT 6 M6X35 221A0047
66
4111410307 NUT HEX 4 1 M4 221F0082
67
4111410505 NUT HEX 5 1 M5 221F0085
68
4111410901 NUT HEX 8 1 M8 221F0089
69
4110511708 SCR TRS 4X6 8 M4X6 TRS 221E0532
71 4111412806 WASHER SPR 3 2 SW3 221H0281
72
4111412905 WASHER SPR 4 18 SW4 221H0284
73
4111416705 WASHER SPR 5 38 SW5 221H0287
74
4111413001 WASHER SPR 6 16 SW6 221H0289
76
4111413902 WASHER V 3X7X0.5 4 FW3 221H0312
77
4111414008 WASHER V 4X9X0.8 22 FW4 221H0315
78
4111414107 WASHER V 5X10X1 30 FW5 221H0318
79
4111414305 WASHER V 6X12.5X1.6 16 FW6 221H0320
