MODEL GXH-1 1012-005 91 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE N-7 604 6301315379 BRACKET 2 803N--210-004 21 1F8980 605 6301233192 SHAFT 6 803N--210-005 213A1012 606 6301233031 COLLAR 6 803N--210-006 2…
MODEL GXH-1
0503-003
90
コンベア部
CONVEYOR SECTION
Fig. N-7
バックアップ上下駆動部
Back-up Leveller Driver
658
.
664
.
669
653
.
661
.
666
656
.
662
.
667
654
.
661
.
666
655
.
661
.
666
657
.
663
.
668
651
676
609
610
651
676
619
620
621
625
606
625
607
605
604
623
622
614
616
652
661
676
608
MODEL GXH-1
1012-005
91
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
N-7
604 6301315379 BRACKET 2 803N--210-004 211F8980
605 6301233192 SHAFT 6 803N--210-005 213A1012
606
6301233031 COLLAR 6 803N--210-006 216A11
11
607 6301233048 COLLAR 6 803N--210-007 216A11
12
608 6301232669 PLATE 2 803N--210-008 211D9253
609 6301276717 BASE 4 803N--210-009 210A2168
610
6301233178 ROD 2 803N--210-010 216C0696
614
6301233055 COLLAR 2 803N--210-014 216A11
13
616 6301236605 BALL SCREW 8 803N--210-016 223B0351
619
6301236469 PULLEY,TIMING 2 803N--210-019 223Q0542
620
6301236476 PULLEY,TIMING 8 803N--210-020 223Q0543
621
6301236803 BELT,TIMING 2 803N--210-021 223L0263
622
6301236896 COUPLING 2 803N--210-022 223C0198
623
6301236964 MOTOR,AC-SERVO 2 -M53 803N--210-023 4M150189
625 6300969009 BEARING,RADIAL 12 803N--210-425 222D0343
651
6300007558 BOLT,HEX-SCT 8 M3X16 221A0010
652
6300007619 BOLT,HEX-SCT 32 M4X8 221A0016
653
6300007626 BOLT,HEX-SCT 4 M4X10 221A0017
654
6300007640 BOLT,HEX-SCT 48 M4X14 221A0019
655
6300007671 BOLT,HEX-SCT 32 M4X25 221A0022
656
6300007749 BOLT,HEX-SCT 4 M5X10 221A0029
657
6300007886 BOLT,HEX-SCT 8 M6X16 221A0043
658
6300008012 BOLT,HEX-SCT 2 M8X20 221A0056
661
4111412905 WASHER SPR 4 116 SW4 221H0284
662 4111416705 WASHER SPR 5 4 SW5 221H0287
663
4111413001 WASHER SPR 6 8 SW6 221H0289
664
4111413100 WASHER SPR 8 2 SW8 221H0291
666
4111414008 WASHER V 4X9X0.8 84 FW4 221H0315
667
4111414107 WASHER V 5X10X1 4 FW5 221H0318
668
4111414305 WASHER V 6X12.5X1.6 8 FW6 221H0320
669
4111414503 WASHER V 8X17X1.6 2 FW8 221H0323
676
4111409905 NUT HEX 3 8 M3 221F0079
MODEL GXH-1
0409-002
92
コンベア部
CONVEYOR SECTION
Fig. N-8 NA,NB,NC
シュート１
NA,NB,NC Chute 1
754
.
767
.
772
754
.
767
.
772
759
.
768
.
773
753
.
767
.
772
758
.
767
.
772
760
.
768
.
773
751
.
766
.
771
758
.
767
.
772
752
.
766
.
771
753
.
767
.
772
752
.
766
.
771
753
.
767
.
772
758
.
767
.
772
760
.
768
.
773
753
.
767
.
772
759
.
768
.
773
758
.
767
.
772
734
742
732
763
762
738
739
701
703
738
707
714
715
716
765
710
721
711
712
727
718
717
712
720
719
743
733
737
750
724
755
749
740
741
745
735
744
749
755
750
746
731
702
704
760
.
768
.
773
757
748
725
757
748
709
705
705
722
729
