In the Remark column,additional information is provided with abbreviation style.

Please check the Remark column to find necessary parts

[Abbreviation]

ACC

accessories

SET

set parts

INT

interchangeable parts

T parts

fixed parts for machine transportation

Before Using The Parts List

1. When ordering parts, check the machine name and serial number and then refer to this part list for the correct drawing number,

code number, quantity, description and rating. If the correct ordering method is not used, delivery errors may occur.

3. This parts list is subject to change without notice.

2. If additions or changes have been made to the specifications of your machine, contact your Fuji representative before ordering parts.

Legend

-Main title

This is the name of the unit in the exploded diagram.

-Diagram and list numbers

Use these numbers to find items in both the diagram and part list.

Some numbers are missing from the list. These are not errors or items

to be added later. These items have been removed from the lists due to

machine changes. These items have also been removed from the illustrations.

-Description

-Rating

-Materials

The following symbols are used for the material of the parts.

FE:Iron AL:Aluminum CO:Copper PL:Plastic OT:Other

-Quantity

The number listed in the QTY column is the number of units used in that area

of the machine, not the entire machine. Even though the part or code number

may be the same, the number of parts used may change depending on the location.

-Drawing and code numbers

The part numbers for parts in Fuji Machine products are composed of

alphanumeric characters.
