G-S146-03 0509-001 20 プロフローユニット取付本体対応 Main Machine Modification For Attaching Pro Fiow Uni t P-S146-03(TPM-100/1 10) P-S146-03(TPM-100/1 10) Fig. F A-1 スキージヘッド部 SQUEEGEE HEAD SECTION - エア配管、電装部 - Air Piping, Electrical Pa…
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
P-S146-02
0509-001
19
FB-1
42 630 080 5420 PIPE FITTINGS 4
44 630 069 0538 PIPE FITTINGS 1
46 630 003 6541 AIR LINE EQPT 2
47 630 088 4470 PIPE FITTINGS 1
49 630 118 3466 PIPE FITTINGS 4
52 630 089 2123 SOLENOID VALVE 1 YSV06A,06B
71 630 000 7671 BOLT,HEX-SCT 2 M4X25
72 411 141 2905 WASHER SPR 4
23→25
782FB-110-072
73 411 141 4008 WASHER V 4X9X0.8
23→25
782FB-110-073
G-S146-03
0509-001
20
プロフローユニット取付本体対応
Main Machine Modification For Attaching Pro Fiow Uni
t
P-S146-03(TPM-100/110) P-S146-03(TPM-100/110)
Fig. FA-1
スキージヘッド部
SQUEEGEE HEAD SECTION
- エア配管、電装部
-
Air Piping, Electrical Parts
See Fig.FB-1
Key No.25
24
11
10
12
27
65
67
68
30
9
11
25
10
5
72
71
69
9
22
48
36
38
47
68
67
65
68
67
65
77
41
59
62
45
85
68
67
66
11
10
12
30
65
67
68
40
51
52
52
61
77
77
34
77
28
EXCHANGE
EXCHANGE
EXCHANGE
EXCHANGE
ADD
83
82
81
37
53
50
53
35
9
11
10
5
9
50
76
75
84
60
52
53
55
52
50
52
56
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
P-S146-03
0509-001
21
FA-1
24 630 088 0311 PLATE 1→0 748FA-110-024, 748FA-210-024
25 630 088 0328 STAY 1→0 748FA-110-025, 748FA-210-025
27 630 094 3399 BRACKET 1→0 748FA-110-027, 748FA-210-027
28 630 094 3337 COVER 1→0 748FA-110-028, 748FA-210-028
34 630 115 2295 COVER 1
35 630 115 2288 BOX 1
36 630 114 9257 STAY 1
37 630 114 9264 STAY 1
38 630 114 9271 COVER 1
40 630 097 3310 BRACKET 1
41 630 111 7041 BLOCK 1
45 630 080 5420 PIPE FITTINGS 6
47 630 114 9301 PIPE FITTINGS 1
48 630 114 9318 PIPE FITTINGS 1
50 630 109 0801 VALVE 4
51 630 092 8457 AIR LINE EQPT 1
52 630 069 0538 PIPE FITTINGS 9
53 630 088 4432 PIPE FITTINGS 6
55 630 116 4908 PIPE FITTINGS 2
56 630 109 0788 PIPE FITTINGS 2
59 630 003 6541 AIR LINE EQPT 2
60 630 088 4470 PIPE FITTINGS 1
61 630 111 2435 PIPE FITTINGS 1
62 630 119 6619 SOLENOID VALVE 1 YSV06A,06B,06C
65 630 000 7626 BOLT,HEX-SCT
6→12
748FA-110-065, 748FA-210-065
66 630 000 7671 BOLT,HEX-SCT 6→8 748FA-110-066, 748FA-210-066
67 411 141 2905 WASHER SPR 4
14→22
748FA-110-067, 748FA-210-067
68 411 141 4008 WASHER V 4X9X0.8
12→20
748FA-110-068, 748FA-210-068
69 630 000 7749 BOLT,HEX-SCT 4→2 748FA-110-069, 748FA-210-069
71 411 141 6705 WASHER SPR 5
16→14
748FA-110-071, 748FA-210-071
72 411 141 4107 WASHER V 5X10X1
16→14
748FA-110-072, 748FA-210-072
75 411 141 3100 WASHER SPR 8
8→10
748FA-110-075, 748FA-210-075
76 411 141 4503 WASHER V 8X17X1.6
8→10
748FA-110-076, 748FA-210-076
77 411 051 1708 SCR TRS 4X6 6→8 748FA-110-077, 748FA-210-077
81 630 000 7510 BOLT,HEX-SCT 2 M3X8
82 411 141 2806 WASHER SPR 3 2 SW3
83 411 141 3902 WASHER V 3X7X0.5 2 FW3
84 411 141 0901 NUT HEX 8 2 M8
85 411 113 7501 SCR TRS 4X10 2 M4X10 TRS
