Page
SAMSUNG TECHWIN
21
SM411
Backup Table Ass’y
8
7
17
10
24
22
2
22
23
24
22
24
22
24
1
3
4
5
6
8
6
9
11
11
1
2
1
3
1
5
14
1
6
1
8
1
8
1
9
1
9
1
9
2
0
2
1
1
2
2
3
1
5
2
5
1
5
1
5
2
5
1
5
Page
SAMSUNG TECHWIN
22
SM411
Backup Table Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE
Old No. Stock Apply
Reference
A-1 0.1
J90531080A SM420_BUT_ASSY J90531080A
2
J90531080A
○ X
1
..2 J70531054A BUT_SENSOR_DOG J70531054A 1 J70531054A
2
..2 J70531052A LOWER_PLATE J70531052A 1 J70531052A
3
..2 J70531051A BACK_UP_PLATE J70531051A 1 J70531051A
4
..2 J70531053A UPPER_PLATE J70531053A 1 J70531053A
5
..2 J3212002A PHOTO SENSOR 1 EE-SX670A
○
6
..2 J6015064000 SHOULDER SCREW[MSB6-40] 2 MSB6-40
○
7
..2 J6107047A SPRING[SWU26-70] 1 SWU26-70
○
8
..2 J6308003A URETHAN CUSHION[AXNSK15-40] 1 AXNSK15-40
○
9
..2 J6711028A ELBOW FITTING [KQ2L04-01] 2 KQ2L04-01
○
10
..2 J90531003A DRIVING_LINK_ASSY 2 J90531003A
11
...3 J7053792A UPPER LINK PIN[J7053792A] 4 J7053792A
○
12
...3 J7053793A LOWER LINK PIN[J7053793A] 2 J7053793A
○
13
...3 J7053796A LOWER LINK SHAFT[J7053796A] 1 J7053796A
○
14
....4 J7053797A LOWER LINK END[J7053797A] 1 J7053797A
15
....4 J6601005A BALL BEARING 1 688ZZ
○
16
..2 J90531004A FREE_LINK_ASSY 2 J90531004A
17
..2 J90531005A BUT_CYLINDER_ASSY 1 J90531005A
18
...3 J7053794A CYLINDER JOINT PIN[J7053794A] 2 J7053794A
○
19
...3 J7053795A RING FIXER[J7053795A] 3 J7053795A
○
20
...3 J6619062A CYLINDER JOINT[Y-032B] 1 Y-032B
○
21
...3 J67010088B CYLINDER CM2C32-50-XC3BB 1 CM2C32-50-XC3BB
22
..2 J90531006A LOWER_BEARING_ASSY 8 J90531006A
23
...3 J7053790A LOWER BEARING HOLDER[J7053790A] 1 J7053790A
○
24
..2 J90531007A UPPER_BEARING_ASSY 8 J90531007A
25
...3 J7053791A UPPER BEARING HOLDER[J7053791A] 1 J7053791A
○
P art L is t
Page
SAMSUNG TECHWIN
23
SM411
Base Frame Ass’y
L
C
1
D
0
9
6
B
D
L
C
1
D
0
9
6
B
D
B as e F rame A s s 'y
1
2
3
4
5
6
7
8
