Page
SAMSUNG TECHWIN
33
SM411
Head Ass’y
P art L is t
NO. LEVEL PART NO. PART NAME Q'TY TYPE
Old No. Stock Apply
Reference
81
....4 J71541016A HARNESS_SUPPORT J71541016A 2 J71541016A
COMMON
82
....4 J70541100A CABLE_SPACER J70541100A 1 J70541100A
COMMON
83
....4 J70541017A 2-NIPPLE_BRACKET J70541017A 1 J70541017A
COMMON
84
....4 J70541016A 3-NIPPLE_BRACKET J70541016A 1 J70541016A
COMMON
85
....4 J70541015A CONNECTOR_PANNEL J70541015A 1 J70541015A
COMMON
86
....4 J6719025A GREASE NIPPLE [M6*1.0-STRAIGHT] 5 M6*1.0-STRAIGHT
COMMON
87
....4 J67111015A ELBOW_UNION_FEMALE KQ2LF04-M6 5 KQ2LF04-M6
COMMON
88
....4 J6119056A HANDLE BG-10 1 BG-10
○ COMMON
89
....4 J6103003A HEX SUPPORT 4 M3*5 (BOLT-NUT)
COMMON
90
....4 J6004002038 BUTTON_HEAD_CAP_SCREW M10*20L 1 M10*20L
COMMON
91
...3
J90551079A_A
S
CAMERA_COVER_BOARD_ASSY 1 J90551079A
COMMON
92
....4 J91741025A MEGA_CAMERA_IO_BOARDD VER1.0 1 VER1.0 J90551016A
○ COMMON
93
...3 J90551080A FLY_CAM_ONE_KIT_ASSY_F16 J90551080A 6 J90551080A
94
....4 J6751014A CCD CAMERA[VCC-G20E20] 1 VCC-G20E20
○ COMMON
95
....4 J90591012A SM140165_LENS_ASSY J90591012A 1 J90591012A
○ COMMON
96
....4 J71551125A CAMERA_HOLDER J71551125A 1 J71551125A J7155563A
○ COMMON
97
...3 J90551067A AIR_MODULE J90551067A 1 J90551067A
COMMON
98
....4 J7155546A INSERT[J7155546A] 6 J7155546A
○ COMMON
99
....4 J6711260A ONE TOUCH FITTING[FSE04-M5C] 9 FSE04-M5C
○ COMMON
100
....4 J6702048A SOLENOID VALVE[VA01PEP34-1U-F] 6 VA01PEP34-1U-F
○ COMMON
101
....4 J6702049A SOLENOID VALVE[RCS242-M3-D24NP] 1 RCS242-M3-D24NP
○ COMMON
102
....4 J6711262A MINI FITTING[BC-03-M5] 6 BC-03-M5
○ COMMON
103
....4 J9058090A FILTER ASSY[J9058090A] 6 J9058090A
○ COMMON
104
.....5 J7458002A FILTER ELEMENT[LF-M5-60-Z-ELEMENT] 1 LF-M5-60-Z-ELEMENT
○ COMMON
105
...3 J70551044A AIR_BRACKET_1 J70551044A 1 J70551044A
COMMON
106
...3 J7055662A VACUUM SENSOR BRACKET[J7055662A] 2 J7055662A
COMMON
107
...3 J70551045A AIR_BRACKET_2 J70551045A 1 J70551045A
COMMON
Page
SAMSUNG TECHWIN
34
SM411
Head Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE
Old No. Stock Apply
Reference
108
...3 J71551109A LOWER_LIGHT_COVER J71551109A 1 J71551109A
COMMON
109
...3 J7155572A CAMERA CABLE HOLDER[J7155572A] 1 J7155572A J7155542A
COMMON
110
...3 J1201033 HEX SUPPORT [M3*15 (BOLT-NUT)] 4 M3*15 (BOLT-NUT)
○ COMMON
111
....4 J9060412A SM321 VACUUM SENSOR BOARD[J9060412A] 1 J9060412A
○ COMMON
112
.....5 J3204002A AIR PRESSURE SENSOR [MPX5100AP] 6 MPX5100AP
COMMON
113
....4 J71551117A MANIFOLD J71551117A 1 J71551117A
COMMON
114
....4 J66021024A TIMING_BELT 232-2GT-4 1 232-2GT-4
COMMON
115
....4 J71551010B FIDUCIAL_CAMERA_BRACKET 1 J71551010B
COMMON
116
...3 J6751014A CCD CAMERA[VCC-G20E20] 1 VCC-G20E20
COMMON
117
...3 J90591004A F-MOVING_12058_LENS_ASSY 1 J90591004A
COMMON
118
...3 J90591005A FIDUCIAL_ILL_OUTER_ASSY 1 J90591005A
COMMON
119
....4
J90831175A_A
S
Z1_MOTOR_CABLE_ASSY SM33-MD019 1 SM33-MD019
COMMON [23] at 95 page
120
....4
J90831176A_A
S
Z2 MOTOR CABLE ASS'Y
1
SM33-MD020 COMMON [24] at 95 page
121
....4
J90831177A_A
S
Z3 MOTOR CABLE ASS'Y
1
SM33-MD021 COMMON [25] at 95 page
122
....4
J90831178A_A
S
Z4 MOTOR CABLE ASS'Y
1
SM33-MD022 COMMON [26] at 96 page
123
....4
J90831179A_A
S
Z5 MOTOR CABLE ASS'Y
1
SM33-MD023 COMMON [27] at 96 page
124
....4
J90831180A_A
S
Z6 MOTOR CABLE ASS'Y
1
SM33-MD024 COMMON [28] at 96 page
125
....4
J90831189A_A
S
R12_MOTOR_CABLE_ASSY
1
SM33-MD033 COMMON [29] at 99 page
126
....4
J90831190A_A
S
R34_MOTOR_CABLE_ASSY
1
SM33-MD034 COMMON [30] at 99 page
127
....4
J90831191A_A
S
R56_MOTOR_CABLE_ASSY
1
SM33-MD035 COMMON [31] at 99 page
128
....4 J90831034A R_AUX_SENSOR_CABLE_ASSY SM33-HD002 1 SM33-HD002
COMMON [32] at 89 page
129
....4 J90831035A Z_HOME_SENSOR_CABLE_ASSY SM33-HD003 1 SM33-HD003
COMMON [33] at 89 page
130
....4 J90831039A R_HOME_SENSOR_CABLE_ASSY SM33-HD007 1 SM33-HD007
COMMON [34] at 89 page
131
....4 J90831040A SW_HOME_SENSOR_CABLE_ASSY SM33-HD008 1 SM33-HD008
○ COMMON [35] at 89 page
132
....4 J90831031A HDIO-HILL_CAN_CABLE_ASSY SM33-CA006 1 SM33-CA006
COMMON [36] at 88, 89 page
133
....4 J90831033A HEAD_IO-ILL_POWER_CABLE_ASSY SM33-HD001 1 SM33-HD001
COMMON [37] at 88, 89 page
134
....4 J90831037A HEAD_VACUUM_SOL_CABLE_ASSY SM33-HD005 1 SM33-HD005
COMMON [38] at 90 page
P art L is t
Page
SAMSUNG TECHWIN
35
SM411
Head Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE
Old No. Stock Apply
Reference
135
....4 J90831038A HEAD_BLOW_SOL_CABLE_ASSY SM33-HD006 1 SM33-HD006
COMMON [39] at 90 page
136
....4 J90831041A FLY_OUTER_LED_BD_CABLE_ASSY SM33-HI001 1 SM33-HI001
COMMON [40] at 88 page
137
....4 J90831099A FLAT_FID_CAMERA_CABLE_ASSY SM33-VIS002 1 SM33-VIS002
COMMON [41] at 101 page
138
....4 J90831103A FLY_CAM_PWR-SYNC_EXT_CABLE_ASSY SM33-VIS 1 SM33-VIS006
COMMON [42] at 101 page
139
....4 J90831108A FLYING_CAMERA_I-F_CABLE_ASSY SM33-VIS011 6 SM33-VIS011
COMMON [43] at 101 page
A-2 0.1
J90551102A HEAD_VISION_ASSY-MEGA J90551102A
1
J90551102A
○
140
...3 J90551081A FLY_CAM_ONE_KIT_ASSY_MEGA-F16 J90551081A 6 J90551081A
○
141
....4 J6751015A CCD CAMERA[SFA-205AL] 1 SFA-205AL
○
P art L is t
