VectraES The V ec traES  uxing system is available with foam or spray type systems . A basic foam  uxer is standard with spray  uxing technologies that promote maximum deposition, contr ol, through-hole penetration, a…

VectraES

VectraES:

Available with Foam and Spray

Type Fluxing Systems

Capable of 6’ top and bottom

Preheat

UltraFill™ Nozzle with FloLift™

Technology

Boundary Type, Short and Full

N2 Tunnel Technologies

Solder Pot Height Adjustment

Wet Finger Cleaning System

Manufactured at ITW EAE’s

North American facilities, the

Electrovert VectraES sets the

industry standard for value

leadership in wave soldering

systems.

Advanced Process Capability

Like all Electrovert wave soldering systems, the VectraES

is designed to handle lead-free and di cult applications.

As technology leaders, Electrovert incorporates a number

of features to support di cult and challenging process

environments. The cast iron solder pot and its components are

resistant to the corrosive properties of lead-free solders, and

are capable of withstanding temperatures up to 315

C (600

F).

All stainless steel components that contact solder feature

ElectroCoat™ corrosion-resistant surface conversion, and grade

1 (pure) titanium is available as an option.

• UltraFill with FloLift technology is the ideal nozzle for today’s

lead-free process, promoting positive hole  ll, decreasing the

potential for bridging, and reducing dross generation.

• The VectraES is available with boundary type, short, and long

tunnel N soldering technologies which sets the standard in

the industry for soldering process  exibility and versatility.

Advanced Operator Interface

The VectraES features the familiar Windows® operating system

with user-friendly, pull-down menus. This system supports

networking with other computers, downloading of recipes and

remote access to operating data.

• Storage for 5000+ unique recipes

• Process notes function provides the operator with work and

process instructions tied to the recipes via a data link to a

storage server

• Datalogging traceability feature o ers the capability to

capture important process parameters, either board-based

or time-based

• Security password protection prevents unauthorized

changes to process recipes

• Windows 10 operating system is standard

System-Wide Accessibility

Complete front access is achieved with removable front doors.

The rear of the system features multiple hinged doors providing

access to electrical panels,  uxer,  ux tank and solder pot.

• Drop-down preheaters for easy removal and maintenance

• Automated, roll-out solder pot

• Slide-out  uxer module

VectraES

The VectraES  uxing system is available with

foam or spray type systems. A basic foam  uxer

is standard with spray  uxing technologies

that promote maximum deposition, control,

through-hole penetration, and process

 exibility are optional. The Servo-Spray™, a

servo-controlled, reciprocating spray module

featuring air atomizing nozzle technology

to ensure spray uniformity and positive

hole penetration. A self-cleaning nozzle and

pressure tank  ux delivery system are also

included.

The patented ServoJet™ with FluxJet™ and

the ServoSonic™ spray  uxing systems are

also available as options on the VectraES.

Both high-performance  uxing systems

ensure complete through-hole penetration, a

repeatable process, and reduced  ux usage.

With up to 6’ (1.8m) bottom and 4’ (1.2m) topside, the

VectraES provides exceptional thermal performance and

process  exibility. The VectraES is available with Low Mass

Forced Convection, Radiant IR, and Fast Response Lamp

types of preheat. With the optional quick-connect plug

feature, each one-piece preheat module is interchangeable

for any position and location (top/bottom).

Auto Lead Clearance Adjustment is

a standard feature on the VectraES.

This recipe-driven solder pot height

adjustment feature ensures accuracy

and exceptional process repeatability.

This automatic control also allows

for quick and repeatable changeover

when required.

The solder module consists of a high-capacity cast iron roll-

out solder pot and low-maintenance pump with AC motors.

Con gured with the UltraFill with FloLift technology, available

for air or nitrogen operation, this system is ideal for process

improvements in lead-free soldering. When used in conjunction

with the optional Rotary Chip with FloLift technology, maximum

wetting is achieved, virtually eliminating skips or misses.

The solder pot casting caries a Lifetime Warranty to the original

owner of the machine.

ServoSpray

ServoJet

Auto Lead Clearance

Low Mass Forced Convection

Preheat Module

UltraFill with FloLift

Rotary Chip with FloLift

A robust  nger conveyor with

adjustable width from 2” to 18” (50 mm

to 460 mm) supports various  nger

con gurations. Optional automatic

width adjust and an unload conveyor

extension maximize performance and

productivity.

ServoSonic

Unload Conveyor

Extension

Radiant and Fast Response IR

Preheat Modules

Features:

www.itweae.com

ITW EAE is a division of Illinois Tool Works, Inc. It is a consolidation of all of its Electronic Assembly

Equipment and Thermal Processing Technology. The group includes world-class products from MPM,

Camalot, Electrovert, Vitronics Soltec and Despatch.

Cleaning & Soldering Solutions

Feature VectraES (VES3)

Process

Alloy Type Lead Free (Quali ed and Optimized) S

Process Width Maximum PCB Width S

18” (457 mm)

Physical

Characteristics

Machine Length Length of machine with rail guides (Load/Unload)

136.0” (3.45 m)

157.9” (4.01 m)

Conveyor

Maximum Load Weight

50 lb (22 kg)

Motorized Width O

Preheat

Preheat Type

IR Calrod S

Low Mass Forced Convection

IR Platen and IsoThermal Forced Convection NA

Fast Response IR RFQ

Preheat Length

Bottom

S (Qty. 2) at 4’ (1.2 m)

(Qty. 3) at 6’ (1.8 m)

Top O

(Qty. 2) at 4’ (1.2 m)

Solder

Soldering Environment Environment

SAir

ON

Main Wave UltraFill Air

Dual/Wide Wave

Chip Wave O

DwellMax Plus and DwellMax Ultra NA

Nozzle Material

Melonite Coated, Stainless Steel S

Titanium O

N Soldering

UltraFill N (Boundary Type) O

Short Tunnel (Inerts entire solder pot area) O

Full Tunnel (

Inerts entire solder pot area and injects N into preheat areas for posi-

tion 1 and 2) (No restrictions on preheat type and location)

Wave

Wave Height

S 12.7 mm

O RFQ

ExactaWave (Automatic wave height control) O

Casting Lifetime Warranty on Solder Pot Casting S

HMP High Melting Point Capability (Special Warranty Applies) RFQ

Fluxer

Fluxer Types and

Options

Foam Fluxer S

ServoSpray O

ServoJet O

OA ServoJet O

ServoSonic O

Flux Spray Start/Delay (ServoSpray/ServoSonic) S

Selective Fluxing (includes  ux spray start/delay)

OA Servojet

High speed Servojet

Dual Flux Tank / Single Flux Head

Dual Flux Head / Dual Flux Tank

Te on Coated Flux Tank

Codes and

Operating System

Software and Controls

Windows 10 - 64 bit S

Ethernet Based I/O S

UL UL Certi ed and Listed for Factory Automation Equipment S

CE Certi cation

Training Types of Training

Process, Maintenance, Troubleshooting, and/or Customized Camdenton, MO USA or at Customer Site

Country of Origin Made in USA Factory based R&D, Software Engineering, and Applications Support Camdenton, MO USA

O = Optional; S = Standard; RFQ = Request Factory Quote

Process Knowledge and Support

At ITW EAE, we deliver world-class products, performance, and unparalleled service and support

programs. With the VectraES comes the pro ciency of our Electrovert process experts that allows

us to solve real-world applications issues. Knowledge in Process for superior performance.
