- Write speeds gr eater than 20 Mbytes/second FLASHC ORE III The w orld’ s most trusted pr ogramming engine . Unprec edented per formance & r eliability keeps your production running at maximum velocity Maximize P er…
- Write speeds greater than
20 Mbytes/second
FLASHCORE III
The world’s most trusted programming engine.
Unprecedented performance & reliability keeps your
production running at maximum velocity
Maximize Performance
- Read speeds greater
than 20 Mbytes/second
- Supports large image
le sizes up to 4 Gbytes
- Universal device
support & the
industry’s most
extensive library
of bad block schemes
Proven Quality & Reliability
- *Ensures low noise,
high yield & data
retention
- Supports all Data I/O
manual & automated
systems
- Global service & support
available 24/7
*A LEADING FLASH MEMORY SUPPLIER AND DATA I/O CONDUCTED EXPERIMENTS, DEVELOPED BEST
PRACTICES AND DEMONSTRATED THE RELIABILITY OF PROGRAMMING 20NM DEVICES USING DATA I/O’S
PROGRAMMING SOLUTIONS
Redmond, WA
www.dataio.com
info@dataio.com
+1 800-3-DATAIO
DATA I/O CORPORATION
- Congurable FPGA for
optimized algorithms
• Flash memory (NOR, NAND, MCP, MMC, eMMC, SD,
MoviNAND, OneNAND, iNAND, Serial Flash, EEPROM,
EPROM and more)
• Microcontrollers
• Logic devices (CPLDs, FPGAs, PLDs) and more
UNIVERSAL DEVICE SUPPORT
Americas
Data I/O Corporation
Redmond, Washington, USA
Website: www.dataio.com
Email: sales@dataio.com
Europe
Data I/O GmbH
Gräfelng, Germany
Website: www.dataio.de
Email: salesgmbh@data-io.de
Asia
Data I/O Electronics (Shanghai) Co. Ltd
Shanghai, China, PRC
Website: www.dataio.cn
Email: ChinaSales@dataio.cn
The rst year of support for factory parts and
labor warranty included in purchase price
and can be extended via annual support
agrrement renewal. The APS support
program enables access to new & optimized
algorithms, system software and TaskLink
software updates and hardware support
• Standard burn-in sockets
(5,000-10,000 insertions per socket)
• High Insertion Count (HIC) for BGA,
TSOP, QFP (250,000 insertions per socket)
• NAND Bad Block Schemes
• Serial Number Server
• DataMapper
• Remote Monitor
• Automotive Performance PAK
• ConneX Software
ANNUAL PROGRAMMER SUPPORT (APS)
OPTIONAL DATA I /O SOFTWARE
• 100 Base-T Ethernet
NETWORK INTERFACE PROGRAMMING SOLUTIONS SUPPORTED
• FlashPAK III
• FlashCORE Dekstop
• RoadRunner3
• PSV7000
• PSV5000
• PSV3500
• PSV2800
FLASHCORE III DESKTOP
FLASHCORE III DESKTOP REQUIREMENTS
ADAPTER
& SOCKETING TECHNOLOGY
Create and run jobs for NPI production and seamlessly
transfer programming jobs onto a PSV Automated
Programming System.
The FlashCORE Desktop is designed for programming rst
article builds to conrm functionality prior to high-volume
production runs
COMPUTER REQUIREMENTS
• Operating System:
• Hard Disk Space:
• CD Drive:
• Ethernet Ports:
ELECTRICAL REQUIREMENTS
• Operating Voltage:
• Power Consumption:
• Frequency Range:
ENVIRONMENT REQUIREMENTS
• Operating Temperature
• Humidity:
Windows 10 (32 or 64 bit)
90 MB min for algorithm les,
two applications and additional
jobs
Qty 2
110-240 VAC
100 watts max
50 to 60 Hz
+10
° to +30°C (50° to 86°F)
<90%
Updated: 05-16-23
