30-2
30.旧富士枠対応アダプタ(オプション)(FSFA)
30.Adapter for the old “Fuji Frame”(Option)(FSFA)
30.旧富士枠対応アダプタ(オプション) Adapter for the old “Fuji Frame”(Option)(FSFA)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
1ABSFA2004 1 ADAPTER ｱﾀﾞﾌﾟﾀ
2BSFA1700 1 BLOCK ﾌﾞﾛｯｸ
3BSFA1710 1 BLOCK ﾌﾞﾛｯｸ
4BSFA1720 1 BLOCK ﾌﾞﾛｯｸ
5BSFA1730 1 BLOCK ﾌﾞﾛｯｸ
6BSFA1752 1 ANGLE IRON ｱﾝｸﾞﾙ
7BSFA1760 1 ANGLE IRON ｱﾝｸﾞﾙ
8BSFA1771 1 ANGLE IRON ｱﾝｸﾞﾙ
9BSFA1781 1 ANGLE IRON ｱﾝｸﾞﾙ
10BSFA1812 2 BLOCK ﾌﾞﾛｯｸ
11BSFA1831 2 PLATE ﾌﾟﾚｰﾄ
12GSP4521 3 SPACER ｽﾍﾟｰｻ
13GSP4531 3 SPACER ｽﾍﾟｰｻ
14GSP4541 3 SPACER ｽﾍﾟｰｻ
16H5059T 2 BALL ﾎﾞｰﾙ PC-3C
17BSFA1840 2 LINER ﾗｲﾅ
18H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L
19H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
20W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
21W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L
22W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
23K5186W SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M3X8L
24K5170A SCREW, C/R COUNTERSUNK 小ﾈｼﾞ 十穴皿 M3X12L
25BSFA1740 1 BLOCK ﾌﾞﾛｯｸ
26BSFB2640 1 ROD, PUSH ﾛｯﾄﾞ ﾌﾟｯｼｭ
27BSFB2650 1 ARM, CLAMP ｱｰﾑ ｸﾗﾝﾌﾟ
28BSFB2660 1 ARM, CLAMP ｱｰﾑ ｸﾗﾝﾌﾟ
29TFB3020 4 RETAINER 押え
30K5210A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M4X10L
31R5016A 1
ROLLER, NEEDLE
ﾛｰﾗ ﾆｰﾄﾞﾙ ﾟ4X13.8
32TFB3260 2 COLLAR ｶﾗｰ
33H4130F 1 BEARING ﾍﾞｱﾘﾝｸﾞ 642ZZ
34H5326A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L 全ﾈｼﾞ ･
31.レンズユニット Lenz unit(BSGC)
GP-641E PARTS LIST ver09
31.レンズユニット(BSGC)
31.Lenz unit(BSGC)
31-1
x4
24
26
1
20
7
22
9
11
11
14
6
23
27
27
23
21
17
10
3
15
26
25
13
13
13
12
16
8
17
6
4
19
19
5
11
11
10
22
14
9
7
27
23
26
24
20
2
21
8
27
23
18
18
28
28
28
28
31.レンズユニット Lenz unit(BSGC)
GP-641E PARTS LIST ver09
31-2
31.レンズユニット(BSGC)
31.Lenz unit(BSGC)
番号 図番 & ｺｰﾄﾞ番号 個数 規格 備考
No. Drg. No. & Code No.QTY Rating Remarks
1ABSGC6601 1 LAMP, LED ﾗﾝﾌﾟ LED
2ABSGC6310 1 LAMP, LED ﾗﾝﾌﾟ LED
3ABSGC6322 1 LAMP, LED ﾗﾝﾌﾟ LED
4ABSGC6701 1 LAMP, LED ﾗﾝﾌﾟ LED
5BSGC4022 1 BLOCK ﾌﾞﾛｯｸ
6BSGC6120 2 PLATE ﾌﾟﾚｰﾄ
7BSGC6130 2 PLATE ﾌﾟﾚｰﾄ
8BSGC4053 2 PLATE ﾌﾟﾚｰﾄ
9BSGC6140 2 SHUTTER ｼｬｯﾀ
10BSGC6050 2 ARM ｱｰﾑ
11BSGC6080 4 PIN, PARALLEL ﾋﾟﾝ 平行
12BSGC6102 1 MIRROR ﾐﾗｰ
13BSGC6112 3 MIRROR ﾐﾗｰ
14BSGC6150 2 STOPPER, SWIVELING ｽﾄｯﾊﾟ 旋回
15R4037A 1 LENS ﾚﾝｽﾞ K0094000A01A
16H3242A 1 LENS ﾚﾝｽﾞ K0094000A02A
17S5084T 2 SOL, ROTARY SOL ﾛｰﾀﾘ RS-1
18R2030T 10 RING ﾘﾝｸﾞ HV15X3
19N4029A 2 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め       M4X8
20K5169H 8 SCREW, C/R COUNTERSUNK 小ﾈｼﾞ 十穴皿      M2X4
21K5174Z 4 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋        M1.4X5
22K5175R 4 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋        M2X4
23K5255H 14 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M3X5
24H5273A 6 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴        M3X5
25H5275A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴        M3X8
26W1021A WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ        3M/M
27W1010A WASHER, CONICAL ﾜｯｼｬ 皿         M-3-L
28BSGC6160 4 STOPPER ｽﾄｯﾊﾟ ･
