3-3
3.密閉スキージ(固定部)(BSFS)
3.Hermetic squeegee(Fixed)(BSFS)
3.密閉スキージ(固定部) Hermetic squeegee(Fixed)(BSFS)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
47W10041 1 WASHER ﾜｯｼｬ WSF30
48S1031A 3 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW10
49N1020T 1 NUT, FINE U ﾅｯﾄ ﾌｧｲﾝU FU05SC
50N1020H 1 NUT, FINE U ﾅｯﾄ ﾌｧｲﾝU FU02SC
51S3094A 1 SW, PROXIMITY SW 近接 E2E-X1R5E1
52K5342A 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-06S
53K5337M 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1201F-M5-06
54H5144H 2 BOLT, WING ﾎﾞﾙﾄ 蝶 M5X15
55H1130L 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL VZS2250-5G-01
56H1057T 1 VALVE, ELEC/AIR PROPORTIONALﾊﾞﾙﾌﾞ 電空比例 VY1100-01-BN
57Y3056E 19 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQH06-01S
58Y3049H 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-M5
59Y3051A 12 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-01S
60N1108T 1 NUT, DOMED CAP ﾅｯﾄ 六角袋 M16
61N1085A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0
62N1089A NUT, HEX ﾅｯﾄ 六角 M8 P=1.25 3 Type
63N1092A NUT, HEX ﾅｯﾄ 六角 M10 P=1.5
64N4015A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X4
65W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
66W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
67W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
68W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M
69W1029A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 16M/M
70W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
71W1059A WASHER, FLAT ﾜｯｼｬ 平 16M/MX3.0X30(1W-16)
72W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L
73W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
74W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
75W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
76H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
77H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
78H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
79H5291A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X18L
80H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
81H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
82H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
83H5305A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X30L
84H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
85H5327A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L
86H5329A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X35L
87H5330A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X40L
88K5262B SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M6X12L
89BSFS1493 2 BKT, WIRING BKT 配線 BSFS1491
90W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
3-4
3.密閉スキージ(固定部)(BSFS)
3.Hermetic squeegee(Fixed)(BSFS)
3.密閉スキージ(固定部) Hermetic squeegee(Fixed)(BSFS)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
91S1057A 1 SILENCER ｻｲﾚﾝｻ AN110-01
92K5345A 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2211F-01-06S
93BSFS1472 1 BKT VALVE BKT ﾊﾞﾙﾌﾞ BSFS1471
95H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
97BKFS1510 1 BKT BKT
98BSFS1371 2 PLATE, STOPPER ﾌﾟﾚｰﾄ ｽﾄｯﾊﾟ
99BSFS0191 2 BKT BKT
100Y3048H 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQK06-01S
101K5340T 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2001F-06
102H1128T 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL VT307-5DZ-01-F
103A3034A 1 PLUG 埋め栓 PT-1/8
104K5075A 1 CONNECTOR ｺﾈｸﾀ KQU06-00
105S1022A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ STEW4
106BSFS3111 1 PIN ﾋﾟﾝ
107H31915 1 PLATE, END ﾌﾟﾚｰﾄ ｴﾝﾄﾞ NOS 5T
108BSFS1212 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ
109N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
110BSFS1201 1 SHAFT ｼｬﾌﾄ
111 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
112BSFS7151 1 SPRING ｽﾌﾟﾘﾝｸﾞ ･
注1.No.39 S4060A(ｾﾝｻ)はCLEN6682(ﾊｰﾈｽ)に接続します｡
Note 1 : Use harness CLEN6682 with sensor No.39(S4060A)
4.密閉スキージ(フィーダ) Hermetic squeegee(Feeder)(BSFS)
GP-641E PARTS LIST ver09
4.密閉スキージ(フィーダ)(BSFS)
4.Hermetic squeegee(Feeder)(BSFS)
4-1
x6
72
75
40
19
23
35
36
18
6
7
7
6
1
2
14
15
22
21
98
24
99
100
101
102
103
104
105
106
107
108
109
110
111
142
143
144
145
146
147
148
149
150
151
152
153
154
155
128
129
130
131
132
133
134
135
136
137
138
139
140
141
114
115
116
117
118
119
120
121
122
123
124
125
126
127
89
94
93
49
57
52
58
57
69
55
62
88
92
97
84
90
97
92
96
95
91
74
69
80
80
82
82
86
74
69
85
96
95
91
80
80
79
78
81
81
89
93
94
49
57
52
58
57
69
83
97
92
97
92
90
74
68
87
113
112
76
77
OptionOption
156
A
B
B
A
47
32
56
63
56
63
43
4
43
41
55
60
31
41
55
60
8
41
55
60
41
55
60
28
41
55
60
41
55
60
42
42
29
56
66
41
55
60
37
38
57
70
56
64
56
64
48
48
56
64
56
64
34
57
70
38
37
41
55
60
56
66
42
30
8
28
41
55
60
41
55
60
41
55
60
42
27
41
55
60
41
55
60
31
41
55
60
43
56
63
5
56
63
43
32
47
56
64
56
64
16
67
56
67
56
10
10
57
52
57
52
44
44
33
27
