16.クリーナ上(密閉スキージ用)(オプション) Upper cleaner(For hermetic squeegee)(Option)(BSFC)
GP-641E PARTS LIST ver09
16.クリーナ上(密閉スキージ用)(オプション)(BSFC)
16.Upper cleaner(For hermetic squeegee)(Option)(BSFC)
16-1
x6
69
52
15
4
74
33
14
52
69
22
52
68
50
46
57
65
24
75
29
43
31
25
50
61
32
30
28
26
44
23
27
44
80
42
41
41
82
83
84
85
85
40
40
53
71
92
91
93
94
74
94
74
95
63
56
96
63
56
97
98
98
97
99
100
51
101
100
51
101
99
56
62
102
103
103
62
56
62
56
104
101
51
65
101
51
65
B
54
50
62
20
59
73
21
38
37
36
46
60
13
18
11
45
56
64
56
64
10
59
72
8
56
63
56
63
19
19
9
53
71
7
52
68
39
1
67
51
40
40
6
65
51
76
79
A
8650
64
88
50
89
87
60
46
36
47
47
47
47
12
A
50
105
106
B
16-2
16.クリーナ上(密閉スキージ用)(オプション)(BSFC)
16.Upper cleaner(For hermetic squeegee)(Option)(BSFC)
16.クリーナ上(密閉スキージ用)(オプション) Upper cleaner(For hermetic squeegee)(Option)(BSFC)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
1BSFC3100 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
4CLFC0280 1 SHAFT ｼｬﾌﾄ
6BSFC3160 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ
7BSFC3170 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ
8BSFC3193 1 PLATE ﾌﾟﾚｰﾄ
9BSFC3200 1 JOINT ｼﾞｮｲﾝﾄ
10BSFC3212 1 HOLDER ﾎﾙﾀﾞ
11CLFC0201 1 RETAINER 押え
12BSFC3680 1 MOUNTING BASE 取付台
13CLFC0180 1 PLATE ﾌﾟﾚｰﾄ
14BSFC3610 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
15BSFC3620 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
18CLFC0301 1 PLATE ﾌﾟﾚｰﾄ
19BSFC3180 2 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
20BSFC0361 1 DOG, SW ﾄﾞｯｸﾞ SW
21BSFC0380 1 BLOCK, LOCATING ﾌﾞﾛｯｸ 位置決め
22BSFC3600 1 BKT BKT
23BSFC3420 1 KNUCKLE ﾅｯｸﾙ
24BSFC3320 1 BOSS ﾎﾞｽ
25BSFC3330 1 HOLDER, SPRING 受け ｽﾌﾟﾘﾝｸﾞ
26BSFC3340 1 PIN ﾋﾟﾝ
27BSFC3370 1 PIN ﾋﾟﾝ
28ABSFC3381 1 LINK ﾘﾝｸ
29BSFC3470 1 PIN ﾋﾟﾝ
30MCA0152 1 SPACER ｽﾍﾟｰｻ
31MCA0282 1 SPRING ｽﾌﾟﾘﾝｸﾞ
32MCA0012 3 WHEEL, RATCHET ﾎｲｰﾙ ﾗﾁｪｯﾄ
33BSFC3570 1 HOLDER ﾎﾙﾀﾞ
36S3023W 2 SPRING ｽﾌﾟﾘﾝｸﾞ WM8-15
37H3078Z 1 BUSHING ﾌﾞｯｼｭ F-12X20
38N4011T 1 SCREW, SET ﾈｼﾞ 止め T-5
39K5337M 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1201F-M5-06
40Y3061D 6 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS04-M5
41Y3049Z 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL04-M5
42S2100Y 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQSB25-22DM-F9NL
43H2044H 1 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 2.5ﾟX6
44S1022A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-4
45BSFC0773 1 PAPER ﾍﾟｰﾊﾟ
46N1077H NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 Third Type
47N1080A NUT, HEX ﾅｯﾄ 六角 M4 P=0.7 Third Type
50W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
51W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
52W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
53W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
16-3
16.クリーナ上(密閉スキージ用)(オプション)(BSFC)
16.Upper cleaner(For hermetic squeegee)(Option)(BSFC)
16.クリーナ上(密閉スキージ用)(オプション) Upper cleaner(For hermetic squeegee)(Option)(BSFC)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
54W1040A WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7
55W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4)
56W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L
57W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
59W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
60H5172Z BOLT, HEX ﾎﾞﾙﾄ 六角 M4X30L
61H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L
62H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
63H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L
64H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
65H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
66H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
67H5292A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X20L
68H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
69H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
71H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
72H5327A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L
73H5332T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X55L
74H2041A 5 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 2ﾟX8
75BSFC3360 1 STOPPER ｽﾄｯﾊﾟ
76BSFC3490 1 BKT BKT
79BSFC0782 1 PIPE ﾊﾟｲﾌﾟ
80BSFC5331 1 SHAFT ｼｬﾌﾄ
82BSFC3670 1 NOZZLE ﾉｽﾞﾙ
83BSFC3630 1 HANGER ﾊﾝｶﾞ
84BSFC3640 1 HANGER ﾊﾝｶﾞ
85BSFC7170 2 JOINT ｼﾞｮｲﾝﾄ
86BSFC3520 1 BKT SW BKT SW
87S3141F 1 SW, PHOTOELECTRIC SW 光電
88K5178Z SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X16L
89W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
90K5261T SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ボタン M5X15L
91S1032A 1 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW12
92IPS0190 1 COLLAR ｶﾗｰ
93BSFC3580 1 HOLDER ﾎﾙﾀﾞ
94BSFC3590 2 RING ﾘﾝｸﾞ
95BSFC3540 1 HOUSING ﾊｳｼﾞﾝｸﾞ
96BSFC3530 1 HOUSING ﾊｳｼﾞﾝｸﾞ
97BSFC3550 2 SPRING ｽﾌﾟﾘﾝｸﾞ
98BSFC3560 2 HOLDER ﾎﾙﾀﾞ
99MPA1170 2 WASHER ﾜｯｼｬ
100K5257B SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ボタン M4X10L
101W1043A WASHER ﾜｯｼｬ 4W-4
102BSFC3650 1 HOLDER ﾎﾙﾀﾞ
