1.ダブルスキージ(固定部) Double squeegee(Fixed)(BSFS)
GP-641E PARTS LIST ver09
1.ダブルスキージ(固定部)(BSFS)
1.Double squeegee(Fixed)(BSFS)
1-1
x9
58
63
55
52
69
55
52
69
36
27
1
14
29
4
14
29
79
38
55
52
69
55
52
69
15
13
13
15
21
58
63
58
63
3
47
3
47
20
17
51
31
65
11
40
35
6
73
12
35
28
35
2
8
7
53
49
16
16
65
11
49
53
25
58
62
19
16
16
53
49
53
49
8
2
7
12
35
28
35
40
40
35
73
6
65
11
13
15
69
52
55
15
13
58
63
21
14
29
79
38
1
69
52
55
55
52
69
55
52
69
27
14
29
4
11
65
47
3
58
63
58
63
47
3
20
51
17
31
81
77
50
81
50
77
76
50
77
36
48
58
77
92
50
77
48
58
77
45
43
45
56
54
46
23
30
22
30
52
68
59
66
43
43
9
37
60
70
34
32
33
24
26
39
51
64
A
A
B
50
62
52
67
41
18
B
41
45
43
45
45
43
45
45
74
42
62
50
45
45
75
45
45
45
75
45
41
41
5
57
90
82
83
83
84
85
59
86
87
44
88
89
61
91
5
57
90
82
83
83
84
85
59
86
87
44
88
89
61
91
64
51
51
64
1-2
1.ダブルスキージ(固定部)(BSFS)
1.Double squeegee(Fixed)(BSFS)
1.ダブルスキージ(固定部) Double squeegee(Fixed)(BSFS)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
1BSFS4110 2 PLATE, HOLDER ﾌﾟﾚｰﾄ ﾎﾙﾀﾞ
2BSFS4123 2 LEVER ﾚﾊﾞｰ
3BSFS6020 4 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ
4BSFS4210 2 BOLT, JOINT ﾎﾞﾙﾄ ｼﾞｮｲﾝﾄ
5TFS2640 2 STOPPER ｽﾄｯﾊﾟ
6BSFS3420 2 PIN, PIVOT ﾋﾟﾝ 支点
7BSFS3430 2 BOLT ﾎﾞﾙﾄ
8BSFS3440 2 COLLAR ｶﾗ-
9BSFS0360 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ
11BSFS5620 4 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ Set parts
12BSFS5680 2 KNUCKLE ﾅｯｸﾙ
13BSFS5470 4 BOLT, ADJUSTING ﾎﾞﾙﾄ ｾﾘ
14TFS2160 6 COLLAR ｶﾗｰ
15BSFS5480 4 NUT, LOCK ﾅｯﾄ ﾛｯｸ
16BSFS4170 4 STOPPER ｽﾄｯﾊﾟ
17BSFS4180 2 NUT ﾅｯﾄ
18BSFS4290 1 BKT, VALVE BKT ﾊﾞﾙﾌﾞ
19BSFS4087 1 BKT BKT
20BSFS3413 2 HOLDER ﾎﾙﾀﾞ
21BSFS4311 2 HOLDER ﾎﾙﾀﾞ
22BSFS0300 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ
23BSFS0310 1 BOLT ﾎﾞﾙﾄ
24BSFS0322 1 BOLT, POSITIONING ﾎﾞﾙﾄ 位置決め
25BSFS0331 1 PLATE ﾌﾟﾚｰﾄ
26BSFS0340 1 BKT, SENSOR BKT ｾﾝｻ
27BSFS3050 2 PLATE ﾌﾟﾚｰﾄ
28BSFS5421 2 PIN, SNAP ﾋﾟﾝ ｽﾅｯﾌﾟ
29H4197A 4 BEARING ﾍﾞｱﾘﾝｸﾞ 6802ZZ
30H4138T 2 BEARING ﾍﾞｱﾘﾝｸﾞ HR32005XJ
31K1112A 2 CAM FOLLOWER ｶﾑﾌｫﾛｱ CF05UU-A
32R4012M 1 LEVER, CLAMP ﾚﾊﾞｰ ｸﾗﾝﾌﾟ KKF12
33S30237 1 SPRING ｽﾌﾟﾘﾝｸﾞ WM16-15
34W10041 1 WASHER ﾜｯｼｬ WSF30
35S1031A 6 CIR-CLIP, C-TYPE ｻｰｸﾘｯﾌﾟ C形 STW 10
36S4060A 4 SENSOR ｾﾝｻ 248-04 注1.Note 1
37N1020T 1 NUT, FINE U ﾅｯﾄ ﾌｧｲﾝU FU05SC
38N1020H 2 NUT, FINE U ﾅｯﾄ ﾌｧｲﾝU FU02SC
39S3094A 1 SW, PROXIMITY SW 近接 E2E-X1R5E1
40K5342A 4 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-06S
41H1128T 4 VALVE, SOL ﾊﾞﾙﾌﾞ SOL VT307-5DZ-01-F
42H1057T 1 VALVE, /AIR PROPORTIONAL ﾊﾞﾙﾌﾞ 電空比例 VY1100-01-BN
43Y3056E 17 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQH06-01S
44Y3049H 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-M5
45Y3051A 18 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-01S
1-3
1.ダブルスキージ(固定部)(BSFS)
1.Double squeegee(Fixed)(BSFS)
1.ダブルスキージ(固定部) Double squeegee(Fixed)(BSFS)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
46N1113A 1 NUT, DOMED CAP ﾅｯﾄ 六角袋 KKN16-000CE
47N1086A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0 Third Type
48N1089A NUT, HEX ﾅｯﾄ 六角 M8 P=1.25
49N1092A NUT, HEX ﾅｯﾄ 六角 M10 P=1.5
50W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
51W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
52W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
53W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M
54W1029A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 16M/M
55W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
56W1059A WASHER, FLAT ﾜｯｼｬ 平 16M/MX3.0X30(1W-16)
57W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L
58W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
59W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
60W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
61H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
62H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
63H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
64H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
65H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
66H5305A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X30L
67H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
68H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
69H5329A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X35L
70H5330A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X40L
73S2114H 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQ2D32-45DM-F79L
74S1057A 1 SILENCER ｻｲﾚﾝｻ AN110-01
75K5345A 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2211F-01-06S
76BSFS4400 1 BKT BKT
77H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
79TFS2170 2 COLLAR ｶﾗｰ
81BSFS4230 2 BKT, WIRING BKT 配線
82BSFS3111 2 PIN ﾋﾟﾝ
83S1022A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ STEW-4
84H31915 2 PLATE, END ﾌﾟﾚｰﾄ ｴﾝﾄﾞ NOS 5T
85N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
86BSFS7141 2 SPRING ｽﾌﾟﾘﾝｸﾞ
87BSFS3535 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
88BSFS3542 2 PISTON ﾋﾟｽﾄﾝ
89BSFS1201 2 SHAFT ｼｬﾌﾄ
90BSFS1222 2 ROD, JOINT ﾛｯﾄﾞ ｼﾟｮｲﾝﾄ
91BSFS7171 2 GUIDE, SPRING ｶﾞｲﾄﾞ ｽﾌﾟﾘﾝｸﾞ
92BSFS3510 1 COVER, WIRING ｶﾊﾞｰ 配線
