2 0 . 温調ユニット、照明 H e a t e r , C o o l e r , L a m p ( B S F S ) GP-641E P ARTS LIST ver09 2 0 . 温調ユニット、照明( B S F S ) 2 0 . H e a t e r , C o o l e r , L a m p ( B S F S ) 2 0 - 1 x 1 5 1 6 1 4 1 2 6 1 7 3 2 5 1 1 1 3 1 5…
19-3
19.クリーナ連結部(ダブルスキージ用)(オプション)(BSFC)
19.Cleaner coupling unit(For double squeegee)(Option)(BSFC)
19.クリーナ連結部(ダブルスキージ用)(オプション) Cleaner coupling unit(For double squeegee)(Option)(BSFC)
GP-641E PARTS LIST ver09
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
46. SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X8L
47H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
48H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X15L
49H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
50H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
51H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
52H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
54H5293A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X25L
55H5311A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X60L
56H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
57H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
58H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L
59H5307A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X40L
60BSFC2151 1 BKT BKT
61BSFC7320 1 PIN ﾋﾟﾝ
62BSFC7050 1 BKT, SENSOR BKT ｾﾝｻ
63BSFC7060 1 BLOCK ﾌﾞﾛｯｸ
64BSFC7021 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ
65BSFC7030 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ
66NPT0750 1 BKT BKT
67S2115E 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDY1S15H-K6878-500
68S3099M 1 SW, PROXIMATE SW 近接 TL-W1R5MC1
69H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
70Y3051A 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-01S
71K5342A 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-06S
72BSFC0830 1 DOG ﾄﾞｯｸﾞ
73BSFC0720 1 BKT, SENSOR BKT ｾﾝｻ
74H1051F 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ CV01-01-BF-1.0
75Y3032T 1 UNION ﾕﾆｵﾝ PTV-1/8-BS
76A40305 6 ELBOW ｴﾙﾎﾞ PL1/8-PT1/8-BS
77MCA0760 1 CAP ｷｬｯﾌﾟ
78Y30490 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL04-6M
79N4024A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X12L
80N1076A NUT, HEX ﾅｯﾄ 六角 M3P=0.5
81H5120R 8 BOLT ﾎﾞﾙﾄ ﾌｼﾞﾛｯｸﾎﾞﾙﾄ N型BﾀｲﾌﾟM4X15L
83BSFC7420 2 BLOCK ﾌﾞﾛｯｸ ･
20.温調ユニット、照明 Heater,Cooler,Lamp(BSFS)
GP-641E PARTS LIST ver09
20.温調ユニット、照明(BSFS)
20.Heater,Cooler,Lamp(BSFS)
20-1
x15
16
14
12
6
17
3
2
5
11
13
15
9
11
13
18
8
4
10
13
1
19
7
20
21
20.温調ユニット、照明 Heater,Cooler,Lamp(BSFS)
GP-641E PARTS LIST ver09
20-2
20.温調ユニット、照明(BSFS)
20.Heater,Cooler,Lamp(BSFS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg. No. & Code No.QTY Description Rating Remarks
1BSFS1510 1 BKT BKT
2TWH0070 4 BKT BKT
3TWH0080 4 COLLAR ｶﾗｰ
4JPA0030 1 HEATER ﾋｰﾀ
5K3001Z 1 COOLER ｸｰﾗ INSPAC-12HC.100W
6H5359T 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X20L P=1.25
7T1013T 1 TANK ﾀﾝｸ 5-037-02 10L
8H3012T 1 FAN ﾌｧﾝ 109E1724F5H01
9K1082D 1 COVER, FAN ｶﾊﾞｰ ﾌｧﾝ 109-319
10H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
11H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
12. BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X16L
13W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
14W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
15W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
16W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8
17W1047A WASHER, FLAT ﾜｯｼｬ 平 4W-10
18N1080A NUT, HEX ﾅｯﾄ 六角 M4P=0.7
19S2008A 1 ILLUMINATION LAMP 照明灯 HF1071
20T1064H 1 DUCT ﾀﾞｸﾄ 12HC-3-BSWH
21K5216A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M6X10L ･
