5OM-1610 3-1 Parts Location 101 1-002 D(01600) Layout under the Base (General View) CPU-1,-2 LAN I/F Intermediate Conveyor I/F (L) OP Panel RB Side Panel R Noise Filter Air Inlet FAN DC Power Supply LED Lighting Control …

100%1 / 215
5OM-1610
0911-001 3-B
5OM-1610
3-1
Parts Location
1011-002 D(01600)
Layout under the Base (General View)
CPU-1,-2
LAN I/F
Intermediate Conveyor I/F (L)
OP Panel RB
Side Panel R
Noise Filter
Air Inlet FAN
DC Power Supply
LED Lighting Control PCB
Exhaust FAN
Servoamplifier, I/O Board
CPU-Mst1
Front/Rear I/F BOX
Intermediate Conveyor I/F (L)
OP Panel LB
Side Panel C
Side Panel L
5OM-1610
3-2
Parts Location
1011-002 D(01700)
Layout under the Base (DC Power Supply)
M174
M173
F61
M173
G1
G1
G2
G7
C129
G4
G4
G8
G8
To FG Terminal
on the rear of G1
