5OM-1610 3-4 Parts Location 101 1-002 G(01300) Layout under the Base (Side Panel C) B K33A K33B K1 K25 K3 K4 K75 K77 K38 K50 F1 (3A) F2 (6.3A) F5 (6.3A) F7 (6.3A) F41 (3A) F42 (5A) F52 (6.3A) F33 (10A) F34 (10A) F43 (10A…
5OM-1610
3-3
Parts Location
1011-002 G(01300)
Layout under the Base (Side Panel L)
Rear Side
F201 F203
F202
Q201 Q206
Q204
K29 K28 K10
Q205 Q221R Q221R Q221R
Vacuum
Pump
Q221F
X Axis
X Axis Y1 Axis Y2 Axis
Q222F
Y1 Axis
Q223F
Y2 Axis
5OM-1610
3-4
Parts Location
1011-002 G(01300)
Layout under the Base (Side Panel C)
B
K33A
K33B
K1
K25
K3
K4
K75
K77
K38 K50
F1
(3A)
F2
(6.3A)
F5
(6.3A)
F7
(6.3A)
F41
(3A)
F42
(5A)
F52
(6.3A)
F33
(10A)
F34
(10A)
F43
(10A)
F44
(10A)
F29
(6.3A)
F30
(6.3A)
Details B
For 24V Circuit
For 48V Circuit
5OM-1610
3-5
Parts Location
1011-002 G(01300)
Layout under the Base (Side Panel R)
U27
